Tractor · 1974Unverified

Fiat 400E

Name: Fiat 400E
Brand: Fiat

Fiat 400E — Utility tractor · 45 hp. Reference specifications; pending source verification.

The Fiat 400E is a compact tractor with a rated output of 45 hp, placing it among smaller models in its class. It was manufactured between 1974 and 1980. This tractor features a 3-cylinder diesel liquid-cooled engine, coupled with a 6-speed gearbox for two-wheel drive. Its listed weight ranges from 3671 to 4255 pounds, suitable for tasks covering approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

45 hp

Weight

3671 to 4255 pounds

Catalogue coverage

Variants represented

Richest spec table

39 rows

Recorded power

45 hp

Recorded weight

1930 kg

Transmissions

6-speed gear

Production years

1974-1980

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerFiatReference

Utility tractorReference

Built in Sauce Viejo, ArgentinaReference

Two-wheel driveReference

Differential lockmechanical rearReference

Manual steeringReference

Mechanical band brakesReference

Open operator station.Reference

Engine

Fiat 3.4L 3-cyl dieselReference

Fuel tank74.9 LReference

Engine33.6 kWReference

Fiat CN3/615Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement3.4 LReference

Bore/Stroke110 x 120 mmReference

Power33.6 kWReference

Compression17:1Reference

Rated RPM2200Reference

StarterelectricReference

Starter volts12Reference

Transmission

6-speed gearReference

TypegearReference

Gears6 forward and 2 reverseReference

Clutchdry discReference

PTO & Hydraulics

Rear PTO Type540 (1.375)Reference

Dimensions

Row-crop Wheelbase224 cmReference

Standard Wheelbase183 cmReference

Weight3671 to 4255 poundsReference

Row-crop Length370 cmReference

Standard Length311 cmReference

Row-crop Height (steering wheel)184 cmReference

Standard Height (steering wheel)154 cmReference

Row-crop Weight1930 kgReference

Standard Weight1665 kgReference

Front tread130 to 201 cmReference

Rear tread124 to 184 cmReference

Speeds

With 14.9-26 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
