Tractor · 1960Unverified
Fiat 411RB
Fiat 411RB — Utility tractor · 39 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
39 hp
Weight
1434 kg
Hover a source tag to verify
Overview
ManufacturerFiatReference
Utility tractorReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
411RutilityReference
411RBgasoline engineReference
411TtricycleReference
411CcrawlerReference
421RorchardReference
431RvineyardReference
441Rfour-wheel driveReference
451Cmountain crawlerReference
481Rhigh-cropReference
Engine
FIAT 1.9L 4-cyl gasolineReference
Engine29.1 kWReference
Belt (claimed)26.1 kWReference
FIATReference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement1.9 LReference
Bore/Stroke82 x 90 mmReference
Power29.1 kWReference
Compression7.5:1Reference
Rated RPM2500Reference
Starter volts24Reference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
PTO & Hydraulics
Rear PTO Type540Reference
Dimensions
Weight1434 kgReference
Front tire6.00-16Reference
Rear tire11-28Reference
Ag front6.00-16Reference
Ag rear11-28Reference
Length274 cmReference
Width165 cmReference
Height137 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
