Tractor · 1979Unverified
Fiat 44-23
Fiat 44-23 — 44 Series · 230 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
230 hp
Weight
11902 kg
Hover a source tag to verify
Overview
DistributorFiatReference
ManufacturerVersatileReference
Four-wheel Drive (4WD) tractorReference
Built in Winnipeg, Manitoba, CanadaReference
Four-wheel driveReference
Cab standard with air-conditioning.Reference
Engine
Cummins 14.0L 6-cyl dieselReference
Fuel tank699.8 LReference
Engine171.5 kWReference
Cummins NT-855Reference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement14.0 LReference
Bore/Stroke140 x 152 mmReference
Power171.5 kWReference
Rated RPM2100Reference
Transmission
12-speedReference
Gears12 forward and 3 reverseReference
PTO & Hydraulics
Pressure154.0 barReference
Pump flow90.1 lpmReference
Rear TypeIVReference
Rear lift (at 24"/610mm)9802 kgReference
Rear PTOindependentReference
Rear PTO Type1000 (1.75)Reference
Dimensions
Wheelbase329 cmReference
Weight11902 kgReference
Front tire18.4-38Reference
Rear tire18.4-38Reference
Ag front18.4-38Reference
Ag rear18.4-38Reference
Length643 cmReference
Height329 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
