Tractor · 1990Unverified
Fiat 45-76
Fiat 45-76 — 76 Series · 44 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
44 hp
Weight
3748 to 3946 pounds
Hover a source tag to verify
Overview
ManufacturerFiatReference
Orchard/Vineyard tractorReference
Two- or four-wheel driveReference
Final drivesplanetaryReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post mid-mount ROPS.Reference
Engine
Fiat 2.7L 3-cyl dieselReference
Engine33.1 kWReference
Fiat 8035.06Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.7 LReference
Bore/Stroke100 x 115 mmReference
Power33.1 kWReference
Air cleanerdryReference
Compression17:1Reference
Rated RPM2500Reference
Firing order1-2-3Reference
StarterelectricReference
Starter volts12Reference
Intake valve clearance0.254 mmReference
Exhaust valve clearance0.356 mmReference
Transmission
12-speed partially synchronizedReference
12-speed mechanical shuttleReference
20-speed creeperReference
Typepartially synchronizedReference
Gears12 forward and 4 reverseReference
Clutch254mm dry discReference
Four synchronized gears (1-4) in three ranges (I-III) plus reverse range. Tractor must be stopped, and clutch used, to shift range.Reference
Typemechanical shuttleReference
Gears12 forward and reverseReference
Four synchronized gears (1-4) in three ranges (I-III) with mechanical reverser.Reference
TypecreeperReference
Gears20 forward and 8 reverseReference
Optional creeper range for the standard 12-speed transmission.Reference
PTO & Hydraulics
Typeopen centerReference
Pressure186.0 barReference
Pump flow32.9 lpmReference
Rear TypeIReference
Controlposition and lower-link draft controlReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@2200Reference
Engine RPM1000@2380Reference
Dimensions
2WD Wheelbase188 cmReference
4WD Wheelbase188 cmReference
Weight3748 to 3946 poundsReference
Front tire5.00-15Reference
2WD Rear tire9.5-28Reference
2WD Standard tires (ag)Front: 5.00-15. Rear: 9.5-28Reference
4WD Standard tires (ag)Front: 6.00-16. Rear: 11.2/12-28Reference
4WD Optional tires (ag)Front: 6.00-16. Rear: 12.4/11-24Reference
4WD Optional tires (ag)Front: 7.00-12. Rear: 11.2/10-24Reference
4WD Optional tires (ag)Front: 7.5L-15. Rear: 12.4/11-24Reference
2WD Length288 cmReference
4WD Length279 cmReference
2WD Ground clearance32 cmReference
4WD Ground clearance22 cmReference
Front tread98/104 cmReference
Rear tread74/85/102/113/114/125 cmReference
2WD1700 kgReference
4WD1789 kgReference
2WD Ballasted1860 kgReference
4WD Ballasted1950 kgReference
2WD Steering wheel135 cmReference
4WD Steering wheel131 cmReference
45-76 Serial Numbers
Location:Serial number plate below the steering column.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Watts (rated)400Reference
Battery volts12Reference
Battery AH100Reference
Fiat 45-76 Height
2WD Hood116 cmReference
4WD Hood120 cmReference
2WD ROPS237 cmReference
4WD ROPS240 cmReference
Speeds
With 9.5/9-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
