Tractor · 1970Unverified
Fiat 455C
Fiat 455C — 55 Series · 47 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
47 hp
Weight
2315 kg
Hover a source tag to verify
Overview
ManufacturerFiatReference
Agricultural Crawler tractorReference
DrivecrawlerReference
Open operator station.Reference
Engine
Fiat 2.6L 3-cyl dieselReference
Engine35.3 kWReference
Fiat 8035.02Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.6 LReference
Bore/Stroke100 x 110 mmReference
Power35.3 kWReference
Starter typeelectricReference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
PTO & Hydraulics
Rear lift1450 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Engine RPM540@1970Reference
Dimensions
Wheelbase129 cmReference
Weight2315 kgReference
9.8-inch tracksReference
Length267 cmReference
Width129 cmReference
Height (hood)120 cmReference
Height (exhaust)165 cmReference
Ground clearance27 cmReference
Gauge101 cmReference
Fiat 455C Tracks
Width24 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
