Tractor · 1959Unverified

Fiat 512R

Name: Fiat 512R
Brand: Fiat

Fiat 512R · 59 hp. Reference specifications; pending source verification.

The Fiat 512R is a tractor rated at approximately 59 hp, placing it towards the lower end of its class in terms of power output. Produced from 1959 to 1960, the 512R features a 4-cylinder diesel liquid-cooled engine and two-wheel drive, paired with a 7-speed gearbox. Its operating weight is listed at 2370 kg, with a capacity for operations on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

59 hp

Weight

2370 kg

Catalogue coverage

Variants represented

Richest spec table

20 rows

Recorded power

59 hp

Recorded weight

2370 kg

Transmissions

7-speed

Production years

1959-1960

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerFiatReference

Two-wheel driveReference

Open operator station.Reference

Engine

FIAT 4.2L 4-cyl dieselReference

Engine44.0 kWReference

FIATReference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.2 LReference

Bore/Stroke105 x 120 mmReference

Power44.0 kWReference

Rated RPM1750Reference

Transmission

7-speedReference

Gears7 forward and 2 reverseReference

Dimensions

Weight2370 kgReference

Front tire6.00-19Reference

Rear tire13-28Reference

Ag front6.00-19Reference

Ag rear13-28Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
