Tractor · 1973Unverified
Fiat 540
Fiat 540 · 54 hp. Reference specifications; pending source verification.
The Fiat 540 is a tractor model rated at 54 hp, positioned as one of the more compact options in its class. It was manufactured from 1973 to 1978. The tractor is equipped with a 3-cylinder diesel liquid-cooled engine, which drives through a 4-wheel drive system paired with an 8-speed gearbox. The listed weight range for the Fiat 540 is 4630 to 5181 pounds.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
54 hp
Weight
4630 to 5181 pounds
Catalogue coverage
Variants represented
2
Richest spec table
34 rows
Recorded power
54 hp
Recorded weight
2100 kg
Transmissions
8-speed gear
Production years
1973-1978
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerFiatReference
Two- or four-wheel driveReference
Open operator station.Reference
Engine
Fiat 2.6L 3-cyl dieselReference
Fuel tank54.1 LReference
Engine40.3 kWReference
FiatReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.6 LReference
Bore/Stroke100 x 110 mmReference
Power40.3 kWReference
Compression17:1Reference
Rated RPM2600Reference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 2 reverseReference
Four gears (1-4), plus reverse (R), in two ranges.Reference
PTO & Hydraulics
Pump flow23.5 lpmReference
Rear TypeII/IReference
Rear lift1549 kgReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase195 cmReference
Weight4630 to 5181 poundsReference
Front tire7.50-16Reference
Rear tire12.4-32Reference
Ag front7.50-16Reference
Ag front9.50-20 (4WD)Reference
Ag rear12.4-32Reference
Length309 cmReference
2WD Weight2100 kgReference
4WD Weight2350 kgReference
Speeds
With 12-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
