Fiat 55-76
Fiat 55-76 — 76 Series · 45 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
45 hp
Weight
3792 to 3990 pounds
Hover a source tag to verify
Overview
ManufacturerFiatReference
Orchard/Vineyard tractorReference
Original price was $19,100 in 1990Reference
Two- or four-wheel driveReference
Final drivesplanetaryReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post mid-mount ROPS.Reference
Engine
Fiat 2.7L 3-cyl dieselReference
Engine40.4 kWReference
Fiat 8035.06Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.7 LReference
Bore/Stroke100 x 115 mmReference
Power40.4 kWReference
Air cleanerdryReference
Compression17:1Reference
Rated RPM2500Reference
Firing order1-2-3Reference
StarterelectricReference
Starter volts12Reference
Intake valve clearance0.254 mmReference
Exhaust valve clearance0.356 mmReference
Transmission
12-speed partially synchronizedReference
12-speed mechanical shuttleReference
20-speed creeperReference
Typepartially synchronizedReference
Gears12 forward and 4 reverseReference
Clutch254mm dry discReference
Four synchronized gears (1-4) in three ranges (I-III) plus reverse range. Tractor must be stopped, and clutch used, to shift range.Reference
Typemechanical shuttleReference
Gears12 forward and reverseReference
Four synchronized gears (1-4) in three ranges (I-III) with mechanical reverser.Reference
TypecreeperReference
Gears20 forward and 8 reverseReference
Optional creeper range for the standard 12-speed transmission.Reference
PTO & Hydraulics
PTO (claimed)33.6 kWReference
Typeopen centerReference
Pressure186.0 barReference
Pump flow32.9 lpmReference
Rear TypeIReference
Controlposition and lower-link draft controlReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@2200Reference
Engine RPM1000@2380Reference
Dimensions
2WD Wheelbase188 cmReference
4WD Wheelbase188 cmReference
Weight3792 to 3990 poundsReference
Front tire5.00-15Reference
2WD V Rear tire9.5-28Reference
2WD V Standard tires (ag)Front: 5.00-15. Rear: 9.5-28Reference
2WD O Standard tires (ag)Front: 5.00-15. Rear: 11.2-24Reference
4WD Standard tires (ag)Front: 6.00-16. Rear: 11.2/10-28Reference
2WD Length288 cmReference
4WD Length279 cmReference
2WD Ground clearance32 cmReference
4WD Ground clearance22 cmReference
2WD V Front tread98/104 cmReference
2WD O Front tread98/108 cmReference
2WD V Rear tread74/85/102/113/114/125 cmReference
2WD O Rear tread87/88/98/99/107/119 cmReference
2WD1720 kgReference
4WD1809 kgReference
2WD Ballasted1880 kgReference
4WD Ballasted1969 kgReference
2WD Steering wheel135 cmReference
4WD Steering wheel131 cmReference
55-76 Serial Numbers
Location:Serial number plate below the steering column.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Watts (rated)400Reference
Battery volts12Reference
Battery AH100Reference
Fiat 55-76 Height
2WD Hood116 cmReference
4WD Hood120 cmReference
2WD ROPS237 cmReference
4WD ROPS240 cmReference
Speeds
With 9.5/9-28 rear tires.Reference
