Fiat 60-76
Fiat 60-76 — 76 Series · 51 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
51 hp
Weight
4564 to 5115 pounds
Hover a source tag to verify
Overview
ManufacturerFiatReference
Orchard/Vineyard tractorReference
Original price was $20,800 in 1990Reference
Two- or four-wheel driveReference
Final drivesplanetaryReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Trailer brakeshydraulicReference
Two-post mid-mount ROPS.Reference
Engine
Fiat 2.9L 3-cyl dieselReference
Engine44.1 kWReference
Fiat 8035.05Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.9 LReference
Bore/Stroke104 x 115 mmReference
Power44.1 kWReference
Air cleanerdryReference
Compression17:1Reference
Rated RPM2500Reference
Firing order1-2-3Reference
StarterelectricReference
Starter volts12Reference
Intake valve clearance0.254 mmReference
Exhaust valve clearance0.356 mmReference
Transmission
12-speed partially synchronizedReference
12-speed mechanical shuttleReference
20-speed creeper shuttleReference
Typepartially synchronizedReference
Gears12 forward and 4 reverseReference
Clutch279.4mm dry discReference
Four synchronized gears (1-4) in three ranges (I-III) plus reverse range. Tractor must be stopped, and clutch used, to shift range.Reference
Typemechanical shuttleReference
Gears12 forward and reverseReference
Clutch254mm dry discReference
Four synchronized gears (1-4) in three ranges (I-III) with mechanical reverser.Reference
Typecreeper shuttleReference
Gears20 forward and 12 reverseReference
Four synchronized gears (1-4) in three ranges (I-III) with mechanical reverser and creeper. The shuttle-creeper lever is moved forward or back for direction control. Pushing the lever down and forward engages the creeper range.Reference
PTO & Hydraulics
PTO (claimed)38.0 kWReference
Typeopen centerReference
Pressure186.0 barReference
Pump flow32.9 lpmReference
Rear TypeII/IReference
Controlposition and lower-link draft controlReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@2200Reference
Engine RPM1000@2380Reference
Dimensions
2WD Wheelbase188 cmReference
4WD Wheelbase199 cmReference
Weight4564 to 5115 poundsReference
Front tire6.00-16Reference
2WD Rear tire12.4-28Reference
2WD Standard tires (ag)Front: 6.00-16. Rear: 12.4-28Reference
2WD Length294 cmReference
4WD Length305 cmReference
2WD Ground clearance42 cmReference
4WD Ground clearance27 cmReference
2WD2070 kgReference
4WD2320 kgReference
2WD Ballasted2285 kgReference
4WD Ballasted2535 kgReference
Steering wheel135 cmReference
60-76 Serial Numbers
Location:Serial number plate below the steering column.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Watts (rated)400Reference
Battery volts12Reference
Battery AH100Reference
Fiat 60-76 Height
Hood122 cmReference
2WD ROPS245 cmReference
4WD ROPS244 cmReference
Speeds
With 12.4-28 rear tires.Reference
