Tractor · 1992Unverified
Fiat 62-85
Fiat 62-85 — 85 Series · 60 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
60 hp
Weight
7606 to 7826 pounds
Hover a source tag to verify
Overview
ManufacturerFiatReference
Agricultural Crawler tractorReference
DrivecrawlerReference
Engine
Fiat 2.9L 3-cyl dieselReference
Engine44.7 kWReference
Fiat 8035.05Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.9 LReference
Bore/Stroke104 x 115 mmReference
Power44.7 kWReference
Rated RPM2000Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speedReference
16-speedReference
Gears8 forward and 4 reverseReference
Gears8 forward and reverseReference
Gears16 forward and 8 reverseReference
PTO & Hydraulics
Rear lift3284 kgReference
Rear PTO Type540Reference
Rear PTO Type540/1000Reference
Rear PTO Type540/750Reference
Dimensions
Wheelbase137 cmReference
Weight7606 to 7826 poundsReference
12.2-inch tracksReference
Length319 cmReference
Width140 cmReference
M Width165 cmReference
Height (hood)119 cmReference
Height (ROPS)221 cmReference
Weight3450 kgReference
M Weight3549 kgReference
Ground clearance26 cmReference
Gauge109 cmReference
M Gauge130 cmReference
Fiat 62-85 Tracks
Width30 cmReference
Width35 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
