Tractor · 1992Unverified
Fiat 65-66S
Fiat 65-66S — 66S Series · 64 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
64 hp
Weight
5159 to 5644 pounds
Hover a source tag to verify
Overview
ManufacturerFiatReference
Utility tractorReference
Two- or four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Four-post ROPS. Cab optional.Reference
Engine
Iveco 3.6L 4-cyl dieselReference
Engine47.9 kWReference
Iveco 8045.05Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.6 LReference
Bore/Stroke100 x 115 mmReference
Power47.9 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed gearReference
12-speed sync shuttleReference
20-speed creeperReference
TypegearReference
Gears12 forward and 4 reverseReference
Typesync shuttleReference
Gears12 forward and reverseReference
TypecreeperReference
Gears20 forward and 12 reverseReference
PTO & Hydraulics
Rear lift3564 kgReference
Rear PTO Type540 (1.375)Reference
Rear PTO Type540/750Reference
Rear PTO Type540/1000Reference
Dimensions
2WD Wheelbase229 cmReference
4WD Wheelbase224 cmReference
Weight5159 to 5644 poundsReference
Front tire6.00-16Reference
2WD Rear tire14.9/13-28Reference
2WD Standard tires (ag)Front: 6.00-16. Rear: 14.9/13-28Reference
4WD Standard tires (ag)Front: 11.2/10-20. Rear: 14.9/13-28Reference
2WD Length341 cmReference
4WD Length341 cmReference
2WD ROPS Weight2340 kgReference
4WD ROPS Weight2560 kgReference
2WD Ground clearance49 cmReference
4WD Ground clearance36 cmReference
2WD Front tread140 to 192 cmReference
4WD Front tread144 to 187 cmReference
Rear tread142 to 192 cmReference
2WD Steering wheel157 cmReference
4WD Steering wheel158 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Fiat 65-66S Height
2WD Hood142 cmReference
4WD Hood139 cmReference
ROPS241 cmReference
Cab232 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
