Tractor · 1993Unverified
Fiat 65-94
Fiat 65-94 — 94 Series · 65 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
65 hp
Weight
6989 to 7496 pounds
Hover a source tag to verify
Overview
ManufacturerFiatReference
Utility tractorReference
Two- or four-wheel driveReference
Final drivesplanetaryReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Cab standard. Four-post ROPS canopy available.Reference
Engine
Fiat 3.6L 4-cyl dieselReference
Fuel tank93.1 LReference
Engine48.5 kWReference
Fiat 8045.06Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.6 LReference
Bore/Stroke100 x 115 mmReference
Power48.5 kWReference
Rated RPM2500Reference
Transmission
12-speedReference
24-speed creeperReference
Gears12 forward and 4 reverseReference
Clutch279mm dry discReference
Gears12 forward and reverseReference
TypecreeperReference
Gears24 forward and 12 reverseReference
PTO & Hydraulics
Pump flow39.0 lpmReference
Rear lift2900 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Dimensions
2WD Wheelbase233 cmReference
4WD Wheelbase231 cmReference
Weight6989 to 7496 poundsReference
Front tire7.50-16Reference
2WD Rear tire16.9/14-30Reference
2WD Standard tires (ag)Front: 7.50-16. Rear: 16.9/14-30Reference
4WD Standard tires (ag)Front: 12.4R20. Rear: 14.9/13-30Reference
2WD Length341 cmReference
4WD Length355 cmReference
Height (hood)143 cmReference
Height (cab)254 cmReference
2WD Weight3170 kgReference
4WD Weight3400 kgReference
2WD Front tread140 to 191 cmReference
4WD Front tread145 to 187 cmReference
Rear tread130 to 199 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
