Tractor · 1969Unverified
Fiat 650
Fiat 650 — Utility tractor · 65 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
65 hp
Weight
2874 kg
Hover a source tag to verify
Overview
ManufacturerFiatReference
Utility tractorReference
Two- or four-wheel driveReference
Open operator station.Reference
Engine
Fiat 3.7L 3-cyl dieselReference
Engine48.5 kWReference
FiatReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement3.7 LReference
Bore/Stroke110 x 130 mmReference
Power48.5 kWReference
Rated RPM2200Reference
Starter volts12Reference
Transmission
7-speedReference
Gears7 forward and 2 reverseReference
PTO & Hydraulics
Pump flow23.5 lpmReference
Rear TypeIIReference
Rear lift2100 kgReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase231 cmReference
Weight2874 kgReference
Front tire7.50-18Reference
Rear tire13.6-36Reference
Ag front7.50-18Reference
Ag front9.50-24 (4WD)Reference
Ag rear13.6-36Reference
Length376 cmReference
Width176 cmReference
Height (steering wheel)173 cmReference
Height (hood)151 cmReference
Speeds
With 12-36 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
