Tractor · 1989Unverified
Fiat 70-56
Fiat 70-56 — 56 Series · 70 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
70 hp
Weight
2694 kg
Hover a source tag to verify
Overview
ManufacturerFiatReference
Utility tractorReference
Two- or four-wheel driveReference
ROPS with canopy.Reference
Variants
70-562WDReference
70-56 DT4WDReference
Engine
Fiat 3.6L 4-cyl dieselReference
Engine52.2 kWReference
Fiat 8045.06Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.6 LReference
Bore/Stroke100 x 115 mmReference
Power52.2 kWReference
Fuel systemdirect injectionReference
Compression17:1Reference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed partially synchronizedReference
12-speed partially synchronizedReference
Typepartially synchronizedReference
Gears8 forward and 2 reverseReference
Four gears (1-4), plus reverse (R), in two ranges (I/II)Reference
Gears12 forward and 3 reverseReference
Four gears (1-4), plus reverse (R), in three ranges (I, II, and III).Reference
PTO & Hydraulics
Rear TypeII/IReference
Rear PTOindependentReference
Rear PTO Type540Reference
Dimensions
2WD Wheelbase220 cmReference
4WD Wheelbase216 cmReference
Weight2694 kgReference
Front tire7.50-16Reference
2WD Rear tire16.9-30Reference
2WD Standard tires (ag)Front: 7.50-16. Rear: 16.9-30Reference
4WD Standard tires (ag)Front: 11.2-24. Rear: 16.9-30Reference
2WD Length346 cmReference
4WD Length355 cmReference
Operating weight2694 kgReference
Ballasted weight3432 kgReference
4WD Ground clearance34 cmReference
2WD Ground clearance53 cmReference
2WD Front tread139 to 199 cmReference
4WD Front tread144 to 187 cmReference
Rear tread131 to 191 cmReference
Steering wheel149 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Fiat 70-56 Height
2WD Hood147 cmReference
4WD Hood144 cmReference
ROPS231 cmReference
2WD Exhaust238 cmReference
4WD Exhaust237 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
