Tractor · 1924Unverified
Fiat 703
Fiat 703 — Standard-tread tractor · 35 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
35 hp
Weight
2700 kg
Hover a source tag to verify
Overview
ManufacturerFiatReference
Standard-tread tractorReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
FIAT 6.2L 4-cyl gasolineReference
Engine26.1 kWReference
Drawbar (claimed)13.4 kWReference
FIATReference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement6.2 LReference
Power26.1 kWReference
Rated RPM1100Reference
Firing order1-3-4-2Reference
Transmission
3-speed unsynchronized gearReference
Typeunsynchronized gearReference
Gears3 forward and 1 reverseReference
Dimensions
Wheelbase134 cmReference
Weight2700 kgReference
Front tire5-32Reference
Rear tire12-51Reference
Ag front5-32Reference
Ag rear12-51Reference
Length320 cmReference
Width165 cmReference
Height190 cmReference
Ground clearance38 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
