Tractor · 1993Unverified
Fiat 72-94
Fiat 72-94 — 94 Series · 70 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
70 hp
Weight
7628 to 8267 pounds
Hover a source tag to verify
Overview
ManufacturerFiatReference
Utility tractorReference
Two- or four-wheel driveReference
Final drivesplanetaryReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Cab standard. Four-post ROPS canopy available.Reference
Engine
Fiat 3.6L 4-cyl dieselReference
Fuel tank93.1 LReference
Engine52.2 kWReference
Fiat 8045.06Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.6 LReference
Bore/Stroke100 x 115 mmReference
Power52.2 kWReference
Rated RPM2500Reference
Transmission
12-speedReference
20-speed creeperReference
24-speed two-speed power shiftReference
Gears12 forward and reverseReference
TypecreeperReference
Gears20 forward and 12 reverseReference
Typetwo-speed power shiftReference
Gears24 forward and 12 reverseReference
PTO & Hydraulics
Pump flow44.7 lpmReference
Rear lift3500 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Dimensions
2WD Wheelbase233 cmReference
4WD Wheelbase231 cmReference
Weight7628 to 8267 poundsReference
Front tire7.50-18Reference
2WD Rear tire13.6-38Reference
2WD Standard tires (ag)Front: 7.50-18. Rear: 13.6-38Reference
4WD Standard tires (ag)Front: 11.2/10-24. Rear: 16.9/14-30Reference
2WD Length355 cmReference
4WD Length368 cmReference
Height (hood)144 cmReference
Height (cab)261 cmReference
2WD Weight3460 kgReference
4WD Weight3749 kgReference
2WD Front tread141 to 192 cmReference
4WD Front tread156 to 199 cmReference
Rear tread139 to 210 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
