Tractor · 1967Unverified
Fiat 750
Fiat 750 · 75 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
75 hp
Weight
6659 to 7474 pounds
Hover a source tag to verify
Overview
ManufacturerFiatReference
Two- or four-wheel driveReference
Open operator station.Reference
Engine
OM 4.6L 4-cyl dieselReference
Fuel tank78.0 LReference
Engine55.9 kWReference
OM CO 3/70Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.6 LReference
Bore/Stroke110 x 120 mmReference
Power55.9 kWReference
Fuel systemdirect injectionReference
Compression17:1Reference
Rated RPM2100Reference
Transmission
7-speed gearReference
TypegearReference
Gears7 forward and 2 reverseReference
PTO & Hydraulics
Pump flow23.5 lpmReference
Rear TypeIIReference
Rear lift2100 kgReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@1830Reference
Dimensions
2WD Wheelbase244 cmReference
Weight6659 to 7474 poundsReference
Front tire6.50-20Reference
2WD Rear tire16.9-34Reference
2WD Standard tires (ag)Front: 6.50-20. Rear: 16.9-34Reference
4WD Standard tires (ag)Front: 9.50-24. Rear: 16.9-30Reference
Length383 cmReference
Width183 cmReference
Height (steering wheel)177 cmReference
Height (hood)151 cmReference
Weight3020 kgReference
Weight3390 kgReference
Clearance (front axle)52 cmReference
Front tread145 to 195 cmReference
Rear tread139 to 199 cmReference
Electrical
GroundnegativeReference
Speeds
With 16.9-34 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
