Tractor · 1975Unverified
Fiat 780
Fiat 780 · 78 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
78 hp
Weight
6482 to 7056 pounds
Hover a source tag to verify
Overview
ManufacturerFiatReference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD (780DT)Reference
Final drivesplanetaryReference
Steeringhydrostatic powerReference
Hydraulic wet disc brakesReference
Trailer brakeshydraulicReference
Open operator station. Optional four-post ROPS. Optional cab with heater.Reference
Variants
7802WDReference
780DT4WDReference
Engine
Fiat 3.7L 4-cyl dieselReference
Fuel tank79.9 LReference
Engine58.2 kWReference
Fiat 8045Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.7 LReference
Bore/Stroke103 x 110 mmReference
Power58.2 kWReference
Fuel systemdirect injectionReference
Compression17:1Reference
Rated RPM2440Reference
Operating RPM1000-2440Reference
Starter volts12Reference
Transmission
8-speedReference
12-speedReference
16-speedReference
Gears8 forward and 2 reverseReference
Four gears in two ranges.Reference
Gears12 forward and 3 reverseReference
Four gears in three ranges.Reference
Gears16 forward and 4 reverseReference
Four gears in four ranges.Reference
PTO & Hydraulics
Typeopen centerReference
Pump flow25.8 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear lift2400 kgReference
Rear Armstelecoping (optional)Reference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Rear PTO Type540/1000 (1.375)Reference
Rear PTO Type1000 (1.75)Reference
Dimensions
2WD Wheelbase226 cmReference
4WD Wheelbase227 cmReference
Weight6482 to 7056 poundsReference
Front tire7.50-18Reference
Rear tire18.4x30 (2WD)Reference
Standard tires (ag)Front: 7.50-18. Rear: 18.4x30 (2WD)Reference
Standard tires (ag)Front: 11.2/10-28. Rear: 13.6/12-38 (4WD)Reference
Length361 cmReference
Width185 cmReference
Height (steering wheel)180 cmReference
2WD Weight2940 kgReference
4WD Weight3200 kgReference
4WD Ground clearance45 cmReference
2WD Ground clearance51 cmReference
Front tread150/160/169/180/193 cmReference
Rear tread139/150/160/169/180/189/199/210 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Battery AH120Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
