Tractor · 1985Unverified
Fiat 80-65
Fiat 80-65 — 65 Series · 79 hp. Reference specifications; pending source verification.
The Fiat 80-65 is a tractor with a rated power output of approximately 79 hp, a mid-range figure for its class. It was manufactured between 1985 and 1989. The 80-65 is equipped with a 4-cylinder liquid-cooled diesel engine and a tracked undercarriage paired with an 8-speed gearbox. Its operating weight is listed at 4100 kg, and it is designed for use on areas of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
79 hp
Weight
4100 kg
Catalogue coverage
Variants represented
2
Richest spec table
36 rows
Recorded power
79 hp
Recorded weight
4100 kg
Transmissions
8-speed
Production years
1985-1989
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerFiatReference
Agricultural Crawler tractorReference
DrivecrawlerReference
Engine
Fiat 3.9L 4-cyl dieselReference
Fuel tank70.0 LReference
Engine58.8 kWReference
Fiat 8045.05Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke104 x 115 mmReference
Power58.8 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speedReference
16-speedReference
Gears8 forward and reverseReference
Gears16 forward and 8 reverseReference
Four gears in two ranges forward, one reverse, with additional creeper range.Reference
PTO & Hydraulics
Rear TypeII/IReference
Rear lift3719 kgReference
Rear PTO Type540Reference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase165 cmReference
Weight4100 kgReference
15.75-inch tracksReference
Length320 cmReference
Width169 cmReference
Height (hood)119 cmReference
Height (ROPS)221 cmReference
Ground clearance26 cmReference
Gauge130 cmReference
Fiat 80-65 Tracks
Width40 cmReference
Width36 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
