Tractor · 1992Unverified
Fiat 82-85
Fiat 82-85 — 85 Series · 80 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
80 hp
Weight
4050 kg
Hover a source tag to verify
Overview
ManufacturerFiatReference
Agricultural Crawler tractorReference
DrivecrawlerReference
Engine
Fiat 3.9L 4-cyl dieselReference
Engine59.7 kWReference
Fiat 8045.05Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke104 x 115 mmReference
Power59.7 kWReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speedReference
16-speedReference
Gears8 forward and 4 reverseReference
Gears8 forward and reverseReference
Gears16 forward and 8 reverseReference
PTO & Hydraulics
Rear lift3719 kgReference
Rear PTO Type540Reference
Rear PTO Type540/1000Reference
Rear PTO Type540/750Reference
Dimensions
Wheelbase165 cmReference
Weight4050 kgReference
TracksReference
Length331 cmReference
Width169 cmReference
Height (hood)119 cmReference
Height (ROPS)221 cmReference
Ground clearance26 cmReference
Gauge130 cmReference
Fiat 82-85 Tracks
Option400mm tracksReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
