Tractor · 1972Unverified
Fiat 850 Super
Fiat 850 Super — Row-Crop tractor · 94 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
94 hp
Weight
7496 to 8267 pounds
Hover a source tag to verify
Overview
ManufacturerFiatReference
Row-Crop tractorReference
Two- or four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Open operator station. Four-post ROPS and cab available.Reference
Variants
850 Supertwo-wheel driveReference
850DT Superfour-wheel driveReference
Engine
Fiat 4.9L 4-cyl dieselReference
Fuel tank85.9 LReference
Engine69.9 kWReference
Fiat OM CO3-80Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.9 LReference
Bore/Stroke110 x 130 mmReference
Power69.9 kWReference
Compression17:1Reference
Rated RPM2100Reference
Firing order1-3-4-2Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speedReference
16-speed creeperReference
Gears12 forward and 4 reverseReference
Clutch304.8mm dry discReference
Four gears in three ranges, plus reverse range.Reference
TypecreeperReference
Gears16 forward and 4 reverseReference
Optional creeper adds an additional range to the transmission.Reference
PTO & Hydraulics
Rear TypeIIReference
Rear lift2600 kgReference
Rear PTO Type540/1000Reference
Dimensions
2WD Wheelbase247 cmReference
4WD Wheelbase251 cmReference
Weight7496 to 8267 poundsReference
Front tire7.50-20Reference
2WD Rear tire16.9/14-38Reference
2WD Standard tires (ag)Front: 7.50-20. Rear: 16.9/14-38Reference
4WD Standard tires (ag)Front: 11.2/10-28. Rear: 16.9/14-38Reference
2WD Length417 cmReference
4WD Length423 cmReference
2WD Width193 cmReference
4WD Width209 cmReference
Height (ROPS)266 cmReference
2WD Weight3400 kgReference
4WD Weight3749 kgReference
2WD Ground clearance56 cmReference
4WD Ground clearance42 cmReference
Electrical
Charging systemalternatorReference
Battery volts12Reference
Speeds
With 16.9/14-38 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
