Tractor · 1974Unverified
Fiat 900E
Fiat 900E — Row-Crop tractor · 113 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
113 hp
Weight
3519 kg
Hover a source tag to verify
Overview
ManufacturerFiatReference
Row-Crop tractorReference
Built in Sauce Viejo, ArgentinaReference
Two-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Mechanical disc brakesReference
Open operator station.Reference
Engine
Fiat 7.4L 6-cyl dieselReference
Fuel tank140.0 LReference
Engine84.3 kWReference
Fiat CP3/620Reference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement7.4 LReference
Bore/Stroke110 x 130 mmReference
Power84.3 kWReference
Rated RPM2200Reference
StarterelectricReference
Starter volts24Reference
Transmission
9-speedReference
Gears9 forward and 2 reverseReference
PTO & Hydraulics
Rear lift3400 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase254 cmReference
Weight3519 kgReference
Front tire10.00x16Reference
Rear tire23.1x30Reference
Ag front10.00x16Reference
Ag rear23.1x30Reference
Length411 cmReference
Height (steering wheel)183 cmReference
Ballasted weight5410 kgReference
Clearance (front axle)51 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
