Tractor · 1990Unverified
Fiat F120
Fiat F120 — Winner Series · 120 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
120 hp
Weight
5100 kg
Hover a source tag to verify
Overview
ManufacturerFiatReference
Row-Crop tractorReference
Two- or four-wheel driveReference
Steeringhydraulic powerReference
Wet disc brakesReference
Cab standard. Air-conditioning optional.Reference
Engine
Iveco 5.9L 6-cyl dieselReference
Fuel tank219.9 LReference
Engine89.5 kWReference
Iveco 8065.05Reference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.9 LReference
Bore/Stroke104 x 115 mmReference
Power89.5 kWReference
Rated RPM2300Reference
Starter typeelectricReference
Transmission
16-speedReference
20-speedReference
32-speedReference
Gears16 forward and reverseReference
Clutchhydraulic cerametallic dry discReference
Four gears in four ranges with synchronized shuttle. Also available as a 32-32 speed creeper.Reference
TransmissionEco-SpeedReference
Gears20 forward and 16 reverseReference
Eco-Speed adds a 40 KPH overdrive to the 16-speed transmission. Also available as a 40-32 speed creeper.Reference
TransmissionHi-LoReference
Gears32 forward and 16 reverseReference
Electro-hydraulic high-low on the base 16-speed transmission. Available in 30 KPH and 40 KPH versions. Also available as 64-32 speed creeper.Reference
PTO & Hydraulics
Pump flow54.9 lpmReference
Rear TypeIIReference
Controlposition control and lower-link draft sensingReference
Rear lift4700 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type540/1000Reference
Rear PTO Type540/750/1000 (optional)Reference
Dimensions
Wheelbase268 cmReference
Weight5100 kgReference
Front tire14.9R28Reference
Rear tire18.4R38Reference
Ag front14.9R28Reference
Ag rear18.4R38Reference
Length465 cmReference
Height280 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
