Tractor · 1993Unverified
Fiat F140
Fiat F140 — Winner Series · 140 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
140 hp
Weight
5300 kg
Hover a source tag to verify
Overview
ManufacturerFiatReference
Row-Crop tractorReference
Four-wheel driveReference
Steeringhydraulic powerReference
Wet disc brakesReference
Cab standard. Air-conditioning optional.Reference
Engine
Iveco 5.9L 6-cyl dieselReference
Fuel tank219.9 LReference
Engine104.4 kWReference
Iveco 8065.25Reference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.9 LReference
Bore/Stroke104 x 115 mmReference
Power104.4 kWReference
Rated RPM2250Reference
Starter typeelectricReference
Transmission
24-speedReference
TransmissionHi-LoReference
Gears24 forward and 12 reverseReference
Clutchhydraulic cerametallic dry discReference
Available in 30 KPH and 40 KPH versions. Also available as a 48-24 speed creeper.Reference
PTO & Hydraulics
Pump flow54.9 lpmReference
Rear TypeIII/IIReference
Controlposition control and lower-link draft sensingReference
Rear lift6568 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type540/1000Reference
Rear PTO Type540/750/1000 (optional)Reference
Dimensions
Wheelbase278 cmReference
Weight5300 kgReference
Front tire16.9-28Reference
Rear tire20.8-38Reference
Standard tires (ag)Front: 16.9-28. Rear: 20.8-38Reference
Optional tires (ag)Front: 420/70R28. Rear: 520/70R38Reference
Optional tires (ag)Front: 480/70R28. Rear: 580/70R38Reference
Length465 cmReference
Height280 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
