Tractor · 1983Unverified
Ford 1110
Ford 1110 — Ten Compact Series · 13 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
13 hp
Weight
1283 to 1396 pounds
Hover a source tag to verify
Overview
DistributorFordReference
ManufacturerShibauraReference
Compact Utility tractorReference
Built in JapanReference
Original price was $6,231 in 1986Reference
Two- or four-wheel driveReference
Final drivesspur gearReference
Differential lockmechanical rearReference
Manual steeringReference
Differential mechanical drum brakesReference
Two-post fixed ROPS.Reference
Engine
Shibaura 0.7L 2-cyl dieselReference
Engine (net)9.7 kWReference
Plows1 (12-inch)Reference
Shibaura LEK 752CReference
dieselReference
2-cylinderReference
liquid-cooledReference
Displacement0.7 LReference
Bore/Stroke75 x 80 mmReference
Power (net)9.7 kWReference
Air cleanerdryReference
Pre-heatingglow plugsReference
Compression23:1Reference
Rated RPM2700Reference
Torque36.2 NmReference
Torque RPM2000Reference
Starter volts12Reference
Oil capacity3.3 LReference
Coolant capacity3.2 LReference
Transmission
10-speed gearReference
hydrostaticReference
15-speed creeperReference
TypegearReference
Gears10 forward and 2 reverseReference
Clutch160mm dry discReference
Oil capacity16.1 LReference
Five gears in two ranges.Reference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
TypecreeperReference
Gears15 forward and 3 reverseReference
Optional creeper provides an additional low range to the gear transmission.Reference
PTO & Hydraulics
PTO (claimed)8.6 kWReference
Hydraulic system16.1 LReference
Typeopen centerReference
Capacity16.1 LReference
Pressure127.5 barReference
Total flow15.5 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at ends)399 kgReference
Gear Rear PTOtransmissionReference
Hydro Rear PTOliveReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2570Reference
Hydro Mid PTOindependentReference
Mid PTO Type1000Reference
Front PTOindependentReference
ClutchelectricReference
Capacities
Fuel18.2 LReference
Dimensions
Wheelbase139 cmReference
Weight1283 to 1396 poundsReference
Front tire4-12Reference
2WD Rear tire8-16Reference
2WD Standard tires (ag)Front: 4-12. Rear: 8-16Reference
4WD Standard tires (ag)Front: 5-12. Rear: 8-16Reference
Lawn/turf front20x8.00-10Reference
Lawn/turf rear29x12.00-15Reference
Length257 cmReference
Width109 cmReference
Height (steering wheel)128 cmReference
Height (ROPS)128 cmReference
2WD Weight581 kgReference
4WD Weight633 kgReference
Ground clearance24 cmReference
2WD Front tread86 to 91 cmReference
4WD Front tread87 cmReference
Rear tread89/104 cmReference
Ford 1110 attachments
48" mid-mount mower deckReference
60" mid-mount mower deckReference
48" rear-mount mower deckReference
snowblowerReference
front-end loaderReference
backhoeReference
1110 Serial Numbers
Location:Transmission housing, left sideReference
1983UB00001Reference
1984UB00785Reference
1985UB01622Reference
1986UB02107Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps35Reference
Charging volts12Reference
Battery volts12Reference
Battery AH72Reference
Attachment overview
48" mid-mount mower deckReference
60" mid-mount mower deckReference
48" rear-mount mower deckReference
SnowblowerReference
Ford 768A loaderReference
Ford 768B loaderReference
BackhoeReference
Among the attachments listed for the Ford 1110 was the model 706 6-cubic-foot rear scoop. Landscaping attachments included the 702A 54-inch front blade, model 781 48-inch rear blade, model 700 48-inch box scraper, and the 762A 72-inch landscaping rake. A 53-inch harrow, 48-inch cultivator, and single-bottom 12-inch plow were matched for field work.Reference
Ford 757A Backhoe
Backhoe typeFord 757A BackhoeReference
Transport height203 cmReference
Bucket width20 cmReference
Bucket width33 cmReference
Bucket width40 cmReference
Digging depth194 cmReference
2-Foot flat digging depth189 cmReference
8-Foot flat digging depth102 cmReference
Reach from pivot271 cmReference
Loading height177 cmReference
Dipperstick force326 kgReference
Speeds
With 8-16 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
