Tractor · 1993Unverified

Ford 1215

Name: Ford 1215
Brand: Ford

Ford 1215 — Fifteen Compact Series · 16 hp. Reference specifications; pending source verification.

The Ford 1215 is a compact tractor with a rated output of 16 hp. It was manufactured from 1993 to 1998. This model is equipped with a 3-cylinder diesel liquid-cooled engine, which drives the four-wheel drive via a hydrostatic transmission. The listed weight range for the Ford 1215 is between 1292 and 1360 pounds.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

16 hp

Weight

1292 to 1360 pounds

Catalogue coverage

Variants represented

Richest spec table

89 rows

Recorded power

16 hp

Recorded weight

586 kg

Transmissions

hydrostatic

Production years

1993-1998

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorFordReference

ManufacturerShibauraReference

Compact Utility tractorReference

Built in JapanReference

Original price was $9,000 in 1998Reference

Two- or four-wheel driveReference

Manual steeringReference

Wet disc brakesReference

Two-post fixed ROPS.Reference

Engine

Shibaura 0.9L 3-cyl dieselReference

Fuel tank18.2 LReference

Engine (gross)11.9 kWReference

Engine (net)10.4 kWReference

Shibaura S723Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement0.9 LReference

Bore/Stroke72 x 72 mmReference

Power (net)10.4 kWReference

Power (gross)11.9 kWReference

Rated RPM2500Reference

StarterelectricReference

Starter volts12Reference

Transmission

hydrostaticReference

6-speed gearReference

TypehydrostaticReference

Gearsinfinite forward and reverseReference

TypegearReference

Gears6 forward and 2 reverseReference

Three gears (1-3), plus reverse (R), in two ranges (L/H).Reference

PTO & Hydraulics

Gear PTO (claimed)10.1 kWReference

Hydro PTO (claimed)9.7 kWReference

Typeopen centerReference

Pump flow14.8 lpmReference

Rear TypeIReference

Rear lift (at ends)668 kgReference

Rear lift (at 24"/610mm)573 kgReference

Gear Rear PTOtransmissionReference

Hydro Rear PTOliveReference

Rear PTO Type540Reference

Mid PTOoptionalReference

Mid PTO Type2000Reference

Dimensions

Wheelbase140 cmReference

Weight1292 to 1360 poundsReference

Front tire4.00x12Reference

2WD Rear tire8x16Reference

2WD Standard tires (ag)Front: 4.00x12. Rear: 8x16Reference

4WD Standard tires (ag)Front: 5x12. Rear: 8x16Reference

Length270 cmReference

Width103 cmReference

Height (ROPS)203 cmReference

2WD Shipping weight586 kgReference

4WD Shipping weight616 kgReference

2WD Ground clearance25 cmReference

4WD Ground clearance24 cmReference

2WD Front tread85 to 89 cmReference

4WD Front tread82 cmReference

Rear tread85 to 99 cmReference

Ford 1215 attachments

48" mid-mount mower deckReference

60" mid-mount mower deckReference

snowblowerReference

bladeReference

front-end loaderReference

backhoeReference

1215 Serial Numbers

Location:transmission housing on leftReference

1993UA20001Reference

1994UA20462Reference

1995UA21150Reference

1996UA21632Reference

1997UA21874Reference

1998UA22187Reference

FAQ: How to read a serial number table.Reference

Electrical

GroundnegativeReference

Battery volts12Reference

Attachment overview

48" mid-mount mower deckReference

60" mid-mount mower deckReference

SnowblowerReference

BladeReference

Front-end loaderReference

BackhoeReference

Ford 756B Backhoe

Backhoe typeFord 756B BackhoeReference

Transport height146 cmReference

2-Foot flat digging depth198 cmReference

8-Foot flat digging depth130 cmReference

Loading height146 cmReference

Bucket Rotation180°Reference

Bucket force873 kgReference

Dipperstick force408 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
