Tractor · 1987Unverified
Ford 1720
Ford 1720 — Twenty Compact Series · 28 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
28 hp
Weight
2491 to 2690 pounds
Hover a source tag to verify
Overview
DistributorFordReference
ManufacturerShibauraReference
Compact Utility tractorReference
Built in JapanReference
Original price was $14,000 in 2000Reference
Two- or four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS.Reference
Engine
Shibaura 1.5L 3-cyl dieselReference
Engine (gross)20.7 kWReference
Engine (net)19.8 kWReference
Shibaura N843Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke84 x 90 mmReference
Power (net)19.8 kWReference
Power (gross)20.7 kWReference
Compression22.5:1Reference
Rated RPM2500Reference
Firing order1-2-3Reference
StarterelectricReference
Starter volts12Reference
Coolant capacity5.6 LReference
Transmission
12-speed gearReference
12-speed mechanical shuttleReference
TypegearReference
Gears12 forward and 4 reverseReference
Three gears (1-3) plus reverse (R) in four ranges.Reference
Typemechanical shuttleReference
Gears12 forward and reverseReference
Four synchronized gears in four ranges, with mechanical shuttle shifting.Reference
PTO & Hydraulics
PTO (claimed)17.5 kWReference
Hydraulic system26.9 LReference
Typeopen centerReference
Capacity26.9 LReference
Pump flow29.5 lpmReference
Total flow40.1 lpmReference
Steering flow10.6 lpmReference
Rear TypeIReference
Controldraft controlReference
Rear lift (at 24"/610mm)790 kgReference
Rear PTOtransmissionReference
Rear PTOliveReference
Rear PTO Type540Reference
Capacities
Fuel32.2 LReference
Dimensions
Wheelbase165 cmReference
Weight2491 to 2690 poundsReference
Front tire5.00-15Reference
2WD Rear tire11.2-24Reference
2WD Standard tires (ag)Front: 5.00-15. Rear: 11.2-24Reference
4WD Standard tires (ag)Front: 7-14. Rear: 11.2-24Reference
Lawn/turf front23x8.50-12Reference
Lawn/turf front25x8.50-14Reference
Lawn/turf rear13.6x16Reference
Length307 cmReference
Width140 cmReference
Height (ROPS)218 cmReference
2WD Shipping weight1129 kgReference
4WD Shipping weight1220 kgReference
Ground clearance29 cmReference
2WD Front tread110 to 146 cmReference
4WD Front tread116 cmReference
Rear tread109 to 149 cmReference
Ford 1720 attachments
72" mid-mount mower deckReference
snowblowerReference
bladeReference
front-end loaderReference
backhoeReference
1720 Serial Numbers
Location:Transmission housing, left sideReference
1987UL21001Reference
1988UL22701Reference
1989UL26556Reference
1990UL28601Reference
1991UL30784Reference
1992UL32230Reference
1993UL33920Reference
1994UL35013Reference
1995UL36435Reference
1996UL37607Reference
1997UL38466Reference
1998UL40069Reference
1999UL41414Reference
2000UL42699Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
72" mid-mount mower deckReference
SnowblowerReference
BladeReference
Front-end loaderReference
BackhoeReference
72" Mower deck
Typemid-mount Ford 914Reference
Type3-bladeReference
Cutting width182 cmReference
Ford 757B Backhoe
Backhoe typeFord 757B BackhoeReference
Transport height180 cmReference
2-Foot flat digging depth215 cmReference
8-Foot flat digging depth165 cmReference
Loading height184 cmReference
Bucket Rotation180°Reference
Bucket force873 kgReference
Dipperstick force426 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
