Industrial Tractor · 1957Unverified

Ford 1841

Name: Ford 1841
Brand: Ford

Ford 1841 — Industrial tractor · 56 hp. Reference specifications; pending source verification.

The Ford 1841 is an industrial tractor with an approximate power rating of 56 hp, positioning it at the lighter end of its class. Produced between 1957 and 1960, the 1841 is equipped with a 4-cylinder diesel liquid-cooled engine, paired with a 4-speed gearbox and two-wheel drive. Its operating weight is listed as 1723 kg. It is suitable for operations of up to 200 ac.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

56 hp

Weight

1723 kg

Catalogue coverage

Variants represented

Richest spec table

115 rows

Recorded power

56 hp

Recorded weight

1723 kg

Transmissions

4-speed unsynchronized gear

Production years

1957-1960

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerFordReference

Industrial tractorReference

Two-wheel driveReference

Steering12x28Reference

Differential mechanical shoe brakesReference

Open operator stationReference

Variants

1811Select-O-Speed, no PTO or hydraulicsReference

1821Four-speed, no PTO or hydraulicsReference

1841Four-speed with PTO and hydraulicsReference

1871Select-O-Speed with PTO and hydraulicsReference

1881Select-O-Speed with multi-speed PTO and hydraulicsReference

Engine

Ford 2.8L 4-cyl gasolineReference

Ford 2.8L 4-cyl dieselReference

Engine42.0 kWReference

FordReference

gasolineReference

4-cylinder 8-valveReference

liquid-cooledReference

Displacement2.8 LReference

Bore/Stroke99 x 91 mmReference

Compression7.5:1Reference

Rated RPM2325Reference

Firing order1-2-4-3Reference

Starter volts6Reference

Coolant capacity14.2 LReference

Sparkplug14MMReference

Sparkplug gap0.686 mmReference

Point gap0.635 mmReference

Intake valve clearance0.381 mmReference

Exhaust valve clearance0.381 mmReference

Oil capacity4.7 LReference

dieselReference

Power42.0 kWReference

Air cleaneroil bathReference

Compression16.8:1Reference

Rated RPM2200Reference

Torque190.4 NmReference

Torque RPM1400Reference

StarterelectricReference

Starter volts12Reference

Transmission

4-speed unsynchronized gearReference

4-speed unsynchronized shuttleReference

Typeunsynchronized gearReference

Gears4 forward and 1 reverseReference

Oil capacity5.7 LReference

Oil typeSAE 80Reference

Unsynchronized transmission operated with gear shift lever and clutch pedal. Tractor must be stopped, and clutch used, to shift gears.Reference

TransmissionReversing TransmissionReference

Typeunsynchronized shuttleReference

Gears4 forward and reverseReference

The optional Reversing Transmission adds a reverser lever to the left side of the tractor. The lever allows an unsychronized shuttle shift by stopping the tractor, using the clutch, and pulling the lever.Reference

Capacities

Fuel64.3 LReference

Rear axle10.9 LReference

PTO & Hydraulics

Hydraulic system7.6 LReference

Capacity7.6 LReference

Pressure137.9 barReference

Total flow15.1 lpmReference

Steering flow30.3 lpmReference

Steering press.103.4 barReference

Rear PTOtransmissionReference

Rear PTO Type540Reference

Dimensions

Wheelbase207 cmReference

Weight1723 kgReference

Front tire7.50x16Reference

Rear tire12x28Reference

Weight1087 kgReference

Weight1217 kgReference

Weight1317 kgReference

Ag rear13x24Reference

Ag rear13x28Reference

Industrial front7.50x16Reference

Industrial rear12x28Reference

Length325 cmReference

Width175 cmReference

Shipping weight1723 kgReference

Front tread137 cmReference

Rear tread132 to 193 cmReference

Ford 1841 attachments

front-end loaderReference

backhoeReference

1841 Serial Numbers

Location:Serial number stamped into the starter mount casting.Reference

19571001Reference

195811977Reference

195958312Reference

1960105943Reference

1961131427Reference

1962155531Reference

FAQ: How to read a serial number table.Reference

Electrical

Groundpositive (6V)Reference

Groundnegative (12V)Reference

Charging systemgeneratorReference

Charging amps20Reference

Batteries1 (gas)Reference

Batteries2 (diesel)Reference

Battery volts6Reference

Battery AH80Reference

Attachment overview

Front-end loaderReference

BackhoeReference

Ford 713 10f Backhoe

Backhoe typeFord 713 10f BackhoeReference

Transport height314 cmReference

Digging depth325 cmReference

Reach from pivot431 cmReference

Loading height287 cmReference

Swing Arc185°Reference

Ford 713 12f Backhoe

Backhoe typeFord 713 12f BackhoeReference

Transport height347 cmReference

Digging depth378 cmReference

Reach from pivot482 cmReference

Loading height322 cmReference

Swing Arc185°Reference

Ford 713 14f Backhoe

Backhoe typeFord 713 14f BackhoeReference

Transport height383 cmReference

Digging depth429 cmReference

Reach from pivot533 cmReference

Loading height355 cmReference

Swing Arc185°Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
