Industrial Tractor · 1957Unverified
Ford 1871
Ford 1871 — Industrial tractor. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Weight
1723 kg
Hover a source tag to verify
Overview
ManufacturerFordReference
Industrial tractorReference
Two-wheel driveReference
Steering12x28Reference
Differential mechanical shoe brakesReference
Open operator stationReference
Variants
1811Select-O-Speed, no PTO or hydraulicsReference
1821Four-speed, no PTO or hydraulicsReference
1841Four-speed with PTO and hydraulicsReference
1871Select-O-Speed with PTO and hydraulicsReference
1881Select-O-Speed with multi-speed PTO and hydraulicsReference
Engine
Ford 2.8L 4-cyl gasolineReference
FordReference
gasolineReference
4-cylinder 8-valveReference
liquid-cooledReference
Displacement2.8 LReference
Bore/Stroke99 x 91 mmReference
Compression7.5:1Reference
Rated RPM2525Reference
Firing order1-2-4-3Reference
Starter volts6Reference
Coolant capacity14.2 LReference
Sparkplug14MMReference
Sparkplug gap0.686 mmReference
Point gap0.635 mmReference
Intake valve clearance0.381 mmReference
Exhaust valve clearance0.381 mmReference
Oil capacity4.7 LReference
Transmission
10-speed power shiftReference
TransmissionSelect-O-SpeedReference
Typepower shiftReference
Gears10 forward and 2 reverseReference
Oil capacity11.4 LReference
Oil typeFord M-2C41Reference
The Select-O-Speed transmission is operated with selector lever. The inching pedal may be used for precision movement of the tractor. The tractor can be shifted on the move without use of the inching pedal. Gear 5, 6, and 9 will free-wheel and cannot be used for engine braking.Reference
Capacities
Fuel64.3 LReference
Rear axle10.9 LReference
PTO & Hydraulics
Hydraulic system7.6 LReference
Capacity7.6 LReference
Pressure137.9 barReference
Total flow15.1 lpmReference
Steering flow30.3 lpmReference
Steering press.103.4 barReference
Rear PTOindependentReference
Rear PTO Type540Reference
Dimensions
Wheelbase207 cmReference
Weight1723 kgReference
Front tire7.50x16Reference
Rear tire12x28Reference
Weight1087 kgReference
Weight1217 kgReference
Weight1317 kgReference
Ag rear13x24Reference
Ag rear13x28Reference
Industrial front7.50x16Reference
Industrial rear12x28Reference
Length325 cmReference
Width175 cmReference
Shipping weight1723 kgReference
Front tread137 cmReference
Rear tread132 to 193 cmReference
Ford 1871 attachments
front-end loaderReference
backhoeReference
1871 Serial Numbers
Location:Serial number on the left side of the tractor, on top of the starter mount casting.Reference
19571001Reference
195811977Reference
195958312Reference
1960105943Reference
1961131427Reference
1962155531Reference
FAQ: How to read a serial number table.Reference
Electrical
Groundpositive (6V)Reference
Groundnegative (12V)Reference
Charging systemgeneratorReference
Charging amps20Reference
Batteries1 (gas)Reference
Batteries2 (diesel)Reference
Battery volts6Reference
Battery AH80Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Ford 713 10f Backhoe
Backhoe typeFord 713 10f BackhoeReference
Transport height314 cmReference
Digging depth325 cmReference
Reach from pivot431 cmReference
Loading height287 cmReference
Swing Arc185°Reference
Ford 713 12f Backhoe
Backhoe typeFord 713 12f BackhoeReference
Transport height347 cmReference
Digging depth378 cmReference
Reach from pivot482 cmReference
Loading height322 cmReference
Swing Arc185°Reference
Ford 713 14f Backhoe
Backhoe typeFord 713 14f BackhoeReference
Transport height383 cmReference
Digging depth429 cmReference
Reach from pivot533 cmReference
Loading height355 cmReference
Swing Arc185°Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
