Industrial Tractor · 1960Unverified
Ford 2000
Ford 2000 — Model year 1960-19621962-1964 · 48 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
48 hp
Weight
1282 kg
Hover a source tag to verify
Overview
ManufacturerFordReference
Industrial tractorReference
Two-wheel driveReference
Steeringpower assistReference
Differential mechanical shoe brakesReference
Open operator station.Reference
Variants
203014-speed, no 3-point or PTOReference
203024-speed, no PTOReference
203034-speedReference
20304Select-O-Speed, no 3-point or PTOReference
20305Select-O-SpeedReference
20306Select-O-Speed, 540/1000 PTOReference
20313LCGReference
Engine
Ford 2.2L 4-cyl gasolineReference
Ford 2.4L 4-cyl dieselReference
Engine36.1 kWReference
FordReference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke87 x 91 mmReference
Power36.1 kWReference
Air cleaneroil bathReference
Compression7.5:1Reference
Rated RPM2200Reference
Torque164.9 NmReference
Torque RPM1600Reference
Firing order1-2-4-3Reference
StarterelectricReference
Starter volts6Reference
Oil capacity4.7 LReference
Coolant capacity14.2 LReference
dieselReference
Displacement2.4 LReference
Bore/Stroke90 x 91 mmReference
Power31.8 kWReference
Compression16:1Reference
Torque150.9 NmReference
Torque RPM1400Reference
Starter volts12Reference
Transmission
4-speed unsynchronizedReference
12-speedReference
4-speedReference
TypeunsynchronizedReference
Gears4 forward and 1 reverseReference
Oil capacity5.7 LReference
TransmissionOver-UnderReference
Gears12 forward and 3 reverseReference
Four-speeds with over-, under-, and direct-drive.Reference
TransmissionReversingReference
Gears4 forward and reverseReference
Capacities
Fuel49.2 LReference
PTO & Hydraulics
Hydraulic system7.6 LReference
Capacity7.6 LReference
Steering flow18.9 lpmReference
Steering press.55.2 barReference
Dimensions
Wheelbase200 cmReference
Weight1282 kgReference
Front tire7.50-16Reference
Rear tire13.6-28Reference
Weight1084 kgReference
Ag rear16.9-24Reference
Industrial front7.50-16Reference
Industrial rear13.6-28Reference
Length323 cmReference
Width162 cmReference
Shipping weight1282 kgReference
Ballasted weight2820 kgReference
Ford 2000 attachments
front-end loaderReference
backhoeReference
2000 Serial Numbers
Location:Serial number stamped into the starter mount casting.Reference
1960105943Reference
1961131427Reference
1962155531Reference
FAQ: How to read a serial number table.Reference
Electrical
Charging systemgeneratorReference
Charging amps20Reference
Battery volts6 (gas)Reference
Battery volts12 (diesel)Reference
Battery AH80 (gas)Reference
Battery AH135 (diesel)Reference
Attachment overview
Ford 703 loaderReference
Ford 720 loaderReference
BackhoeReference
Ford 713 10FT Backhoe
Backhoe typeFord 713 10FT BackhoeReference
Digging depth325 cmReference
Reach from pivot431 cmReference
Loading height284 cmReference
Bucket force2041 kgReference
Speeds
With 12x28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
