Industrial Tractor · 1965Unverified
Ford 2110 LCG Special
Ford 2110 LCG Special — Industrial tractor · 44 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
44 hp
Weight
1465 kg
Hover a source tag to verify
Overview
ManufacturerFordReference
Industrial tractorReference
The Ford 2110 LCG Special used the 3000 series engines instead of the 2000 series engines.Reference
Two-wheel driveReference
Final drivesbevel gearReference
SteeringmanualReference
SteeringpowerReference
Mechanical expanding shoe brakesReference
Open operator station.Reference
Variants
2110 Special3000 series engineReference
Engine
Ford 2.6L 3-cyl gasolineReference
Ford 2.9L 3-cyl dieselReference
Engine (net)32.7 kWReference
FordReference
gasolineReference
3-cylinderReference
liquid-cooled inlineReference
Displacement2.6 LReference
Bore/Stroke107 x 97 mmReference
Power (net)32.7 kWReference
Compression7.75:1Reference
Rated RPM2100Reference
Torque173.6 NmReference
Torque RPM1350Reference
Starter volts12Reference
Oil capacity6.6 LReference
Coolant capacity12.5 LReference
dieselReference
liquid-cooledReference
Displacement2.9 LReference
Bore/Stroke107 x 107 mmReference
Power (net)30.9 kWReference
Air cleanerdryReference
Compression16.5:1Reference
Rated RPM2000Reference
Torque177.6 NmReference
Torque RPM1150Reference
Transmission
6-speedReference
8-speedReference
10-speed power shiftReference
Gears6 forward and 2 reverseReference
Clutch279.4mm dry discReference
Oil capacity13.6 LReference
Gears8 forward and 2 reverseReference
Typepower shiftReference
Gears10 forward and 2 reverseReference
PTO & Hydraulics
PTO (claimed)28.6 kWReference
PTO (claimed)30.3 kWReference
Hydraulic system15.1 LReference
Typeopen centerReference
Capacity15.1 LReference
Pressure172.4 barReference
Valves0 to 2Reference
Steering flow13.2 lpmReference
Rear TypeIReference
Rear lift (at ends)771 kgReference
Rear PTOlive (8-speed)Reference
Rear PTOindependent (10-speed)Reference
Rear PTO Type540Reference
Capacities
Fuel49.2 LReference
Dimensions
Wheelbase192 cmReference
Weight1465 kgReference
Lawn/turf front6.50-13Reference
Lawn/turf rear8.3-24Reference
Lawn/turf front6.00-16Reference
Lawn/turf rear18.4-16AReference
Length321 cmReference
Width174 cmReference
Height (hood)120 cmReference
Height (ROPS)204 cmReference
Ground clearance21 cmReference
Front tread137 to 198 cmReference
Rear tread142 to 190 cmReference
Ford 2110 LCG Special attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemgeneratorReference
Charging amps22Reference
Battery volts12Reference
Gasoline Battery AH80Reference
Speeds
With 8.3-24 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
