Tractor · 1970Unverified

Ford 3055

Name: Ford 3055
Brand: Ford

Ford 3055 — Utility tractor · 55 hp. Reference specifications; pending source verification.

The Ford 3055 is a tractor with a rated power output of 55 hp, positioning it at the lighter end of its class. This model was manufactured from 1970 to 1974. Specification includes a 3-cylinder diesel liquid-cooled engine and four-wheel drive, paired with an 8-speed gearbox. The tractor has an operating weight of 1999 kg, suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

55 hp

Weight

1999 kg

Catalogue coverage

Variants represented

Richest spec table

52 rows

Recorded power

55 hp

Recorded weight

1999 kg

Transmissions

8-speed gear

Production years

1970-1974

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerFordReference

Utility tractorReference

Built in Antwerp, BelgiumReference

Two- or four-wheel driveReference

Final drivesplanetaryReference

Differential lockmechanical rearReference

Manual steeringReference

Wet disc brakesReference

Open operator station.Reference

Engine

Ford 3.0L 3-cyl dieselReference

Engine41.0 kWReference

FordReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement3.0 LReference

Bore/Stroke107 x 112 mmReference

Power41.0 kWReference

Fuel systemdirect injectionReference

Rated RPM2200Reference

Starter volts12Reference

Oil capacity7.6 LReference

Coolant capacity13.2 LReference

Transmission

8-speed gearReference

TypegearReference

Gears8 forward and 2 reverseReference

Clutch279.4mm dry dsicReference

Capacities

Fuel50.0 LReference

PTO & Hydraulics

Hydraulic system26.5 LReference

Capacity26.5 LReference

Rear TypeIReference

Rear TypeIIReference

Controlposition and draft controlReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@1800Reference

Dimensions

Wheelbase198 cmReference

Weight1999 kgReference

Front tire6.00x19Reference

Rear tire12.4/11x36Reference

Ag front6.00x19Reference

Ag rear12.4/11x36Reference

Ag rear14.9/13x28Reference

Length325 cmReference

Width170 cmReference

Height (steering wheel)156 cmReference

Height (hood)147 cmReference

Front tread132 to 203 cmReference

Rear tread132 to 203 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Battery AH128Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
