Ford 3430
Ford 3430 — 30 Utility Series · 38 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
38 hp
Max power
23.6 kW
Weight
4642 to 5490 pounds
Hover a source tag to verify
Overview
ManufacturerFordReference
Utility tractorReference
Original price$20,500 (1999 2WD )Reference
Original price$25,500 (1999 4WD )Reference
Two- or four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post ROPS. Cab optional.Reference
Engine
Ford 3.1L 3-cyl dieselReference
ROPS Fuel tank65.5 LReference
Cab Fuel tank95.8 LReference
Engine34.3 kWReference
Drawbar (tested)23.6 kWReference
FordReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement3.1 LReference
Bore/Stroke112 x 107 mmReference
Power34.3 kWReference
Compression16.3:1Reference
Rated RPM2000Reference
Starter volts12Reference
Coolant capacity10.4 LReference
Power at rated engine speed28.7 kWReference
Max power23.6 kWReference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 2 reverseReference
Clutchdry discReference
PTO & Hydraulics
PTO (claimed)28.3 kWReference
PTO (tested)28.7 kWReference
Typeopen centerReference
Typeclosed centerReference
Pressure172.4 barReference
Valves2 to 4Reference
Pump flow29.1 lpmReference
Pump flow48.4 lpmReference
Steering flow13.6 lpmReference
Rear TypeII/IReference
Controlposition control with top link draft sensingReference
Rear lift1397 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Engine RPM540@1800Reference
Engine RPM540@1755 (shuttle)Reference
Power at rated PTO speed27.5 kWReference
Dimensions
2WD Wheelbase214 cmReference
4WD Wheelbase213 cmReference
Weight4642 to 5490 poundsReference
Front tire6.00-16Reference
Rear tire13.6-28Reference
Ag front6.00-16Reference
Ag rear13.6-28Reference
Length347 cmReference
Width176 cmReference
Ground clearance34 cmReference
2WD ROPS Shipping2105 kgReference
4WD ROPS Shipping2490 kgReference
Operating2462 kgReference
Ford 3430 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps55 (early)Reference
Charging amps45 (late)Reference
Battery CCA800Reference
Battery volts12Reference
Attachment overview
Ford 7209 loaderReference
Ford 7210 loaderReference
Ford 7310 loaderReference
Ford 7410 loaderReference
Ford 3430 Height
ROPS230 cmReference
Cab241 cmReference
Exhaust212 cmReference
Test results
Diesel 8x2 speed 4WDApril 16 - 25, 1991Link: OCED Tractor Test 1643 fileReference
PTO performanceReference
Fuel use9.5 l/hourReference
Fuel use9.1 l/hourReference
Drawbar performanceReference
Gear 1H used for power test.Reference
Max pull2076 kgReference
Gear 2L used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
