Industrial Tractor · 1993Unverified

Ford 345D

Name: Ford 345D
Brand: Ford

Ford 345D — D Series · 58 hp. Reference specifications; pending source verification.

The Ford 345D is a compact industrial tractor with a rating of 58 hp, one of the smaller options in its class. Manufactured between 1993 and 1997, the 345D features a 3-cylinder diesel liquid-cooled engine and four-wheel drive with a hydrostatic transmission. Weights are listed as 8520 to 8740 pounds, and it is suitable for tasks covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

58 hp

Weight

8520 to 8740 pounds

Catalogue coverage

Variants represented

Richest spec table

46 rows

Recorded power

58 hp

Recorded weight

3864 kg

Transmissions

4-speed torque converter

Production years

1993-1997

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerFordReference

Industrial tractorReference

Two- or four-wheel driveReference

Steeringhydrostatic powerReference

Wet multi-disc brakesReference

Two or four-post ROPS.Reference

Engine

Ford 3.3L 3-cyl dieselReference

Engine (gross)43.3 kWReference

Engine (net)40.3 kWReference

FordReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement3.3 LReference

Bore/Stroke112 x 112 mmReference

Power (net)40.3 kWReference

Power (gross)43.3 kWReference

Starter volts12Reference

Transmission

4-speed torque converterReference

8-speed torque converterReference

6-speed manual shuttleReference

Typetorque converterReference

Gears4 forward and reverseReference

Gears8 forward and reverseReference

Typemanual shuttleReference

Gears6 forward and 4 reverseReference

Clutch13-inch organicReference

PTO & Hydraulics

Shuttle PTO (claimed)31.3 kWReference

Gear PTO (claimed)35.8 kWReference

Typeopen centerReference

Pump flow98.4 lpmReference

Rear TypeII/IReference

Controlposition control and top-link draft sensingReference

Rear lift1397 kgReference

Rear PTOindependentReference

Rear PTO Type540Reference

Dimensions

Weight8520 to 8740 poundsReference

Ag front7.50-16 (2WD)Reference

Ag front12.0-16.5 (4WD)Reference

Ag rear16.9-24Reference

Ag rear16.9-28Reference

Weight3864 kgReference

Weight3964 kgReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
