Tractor · 1983Unverified

Ford 3910

Name: Ford 3910
Brand: Ford

Ford 3910 — 10 Utility Series · 50 hp. Reference specifications; pending source verification.

The Ford 3910 is a tractor with a rated power output of 50 hp, categorising it as a lighter model within its class. Manufactured between 1983 and 1989, the 3910 is equipped with a 3-cylinder diesel liquid-cooled engine and four-wheel drive, coupled with an 8-speed gearbox. Its operating weight is specified as 4615 to 5082 pounds, with a suitable area for operation of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

50 hp

Max power

26.6 kW

Weight

4615 to 5082 pounds

Catalogue coverage

Variants represented

Richest spec table

137 rows

Recorded power

50 hp

Transmissions

8-speed

Production years

1983-1989

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerFordReference

Utility tractorReference

Original price was $16,200 in 1989Reference

Two- or four-wheel driveReference

Final drivesinboard planetaryReference

Differential lockmechanical rearReference

Steeringpower assistReference

Differential wet disc brakesReference

Two-post fixed ROPS. Cab optional.Reference

Variants

3910utilityReference

3910NnarrowReference

3910NOlow-profileReference

Engine

Ford 3.1L 3-cyl dieselReference

Engine (gross)37.3 kWReference

Engine35.4 kWReference

Drawbar (tested)26.6 kWReference

FordReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement3.1 LReference

Bore/Stroke112 x 107 mmReference

Power35.4 kWReference

Power (gross)37.3 kWReference

Fuel systemdirect injectionReference

Air cleanerdryReference

Compression16.3:1Reference

Rated RPM2200Reference

Torque187.1 NmReference

Torque RPM1400Reference

Starter volts12Reference

Oil capacity6.6 LReference

Coolant capacity10.4 LReference

Power at rated engine speed31.8 kWReference

Max power26.6 kWReference

Power at rated engine speed31.8 kWReference

Max power26.1 kWReference

Transmission

8-speedReference

8-speed synchromeshReference

6-speed mechanical shuttleReference

TransmissionDual RangeReference

Gears8 forward and 2 reverseReference

Clutch330mm dry discReference

Oil capacity12.0 LReference

TypesynchromeshReference

Gears8 forward and 4 reverseReference

Clutchdry discReference

Oil capacity9.4 LReference

Typemechanical shuttleReference

Gears6 forward and 4 reverseReference

Six-speed transmission became available on the 3910 II in 1986.Reference

PTO & Hydraulics

PTO (claimed)31.3 kWReference

PTO (tested)31.8 kWReference

Hydraulic system45.8 LReference

Typeopen centerReference

Capacity45.8 LReference

Pressure172.4 barReference

Valves1Reference

Pump flow29.1 lpmReference

Pump flow48.4 lpmReference

Steering cap.3.4 LReference

Rear TypeII/IReference

Controlposition and top-link draft controlReference

Rear PTOindependentReference

Rear PTO Type540Reference

Power at rated PTO speed30.1 kWReference

Power at rated PTO speed30.7 kWReference

Capacities

Fuel49.2 LReference

Steering3.4 LReference

Dimensions

2WD Wheelbase196 cmReference

4WD Wheelbase213 cmReference

Weight4615 to 5082 poundsReference

Front tire7.50-15Reference

Rear tire13.6-28Reference

Ag front7.50-15 (2WD)Reference

Ag front8.3-24 (4WD)Reference

Ag rear13.6-28Reference

Ag front5.50-16 (2WD)Reference

Ag front6.00-16 (2WD)Reference

Ag front6.50-16 (2WD)Reference

Ag front7.50-16 (2WD)Reference

Ag front9.5-24 (4WD)Reference

Ag rear14.9-24Reference

Ag rear16.9-24Reference

Ag rear14.9-28Reference

Length323 cmReference

Width176 cmReference

2WD Clearance (front axle)54 cmReference

4WD Clearance (front axle)33 cmReference

Clearance (rear axle)54 cmReference

2WD Front tread132 to 203 cmReference

4WD Front tread142 to 182 cmReference

Rear tread142 to 203 cmReference

@WD Operating2093 kgReference

4WD Operating2305 kgReference

Ballasted3129 kgReference

Steering wheel149 cmReference

Ford 3910 attachments

front-end loaderReference

3910 Serial Numbers

Location:Transmission cover, right-front.Reference

1982C681910Reference

1983C695880Reference

1984C713459Reference

1985C737800Reference

1986C754100Reference

1987C768000Reference

1986BA74292Reference

1987BB05681Reference

1988BB31777Reference

1989BB84620Reference

FAQ: How to read a serial number table.Reference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Mk I Charging amps32Reference

Mk II Charging amps51Reference

Battery volts12Reference

Battery AH128Reference

Attachment overview

Ford 776A loaderReference

Ford 776B loaderReference

Ford 7309 loaderReference

Ford 7310 loaderReference

Ford 3910 Height

Hood133 cmReference

ROPS237 cmReference

Exhaust206 cmReference

Test results

NTTL 1493: diesel 8x2 2WDReference

NTTL 1494: diesel 8x4 2WDReference

Diesel 8x2 2WDSeptember 14 - 26, 1983Link: Nebraska Tractor Test 1493 fileReference

PTO performanceReference

Fuel use10.6 l/hourReference

Fuel use9.5 l/hourReference

Drawbar performanceReference

Fuel use10.2 l/hourReference

Gear 5 used for power test.Reference

Diesel 8x4 2WDSeptember 14 - 26, 1983Link: Nebraska Tractor Test 1494 fileReference

Fuel use9.8 l/hourReference

Max pull2238 kgReference

Gear 2 used for pull test.Reference

Speeds

With 13.6x28 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
