Backhoe Loader · 1993Unverified
Ford 455D
Ford 455D — D Series · 66 hp. Reference specifications; pending source verification.
The Ford 455D is a backhoe loader rated at 66 hp — putting it around the middle of its class for power. It was manufactured from 1993 to 1995. It is powered by a 3-cylinder diesel liquid-cooled engine, driving through four-wheel drive with a 4-speed gearbox. It is aimed at jobs of around up to 200 ac. Detailed specifications in both UK and US units follow below.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
66 hp
Catalogue coverage
Variants represented
2
Richest spec table
43 rows
Recorded power
66 hp
Transmissions
4-speed power shuttle
Production years
1993-1995
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerFordReference
Backhoe loader tractorReference
Two- or four-wheel driveReference
Power steeringReference
Disc brakesReference
Four-post ROPS/FOPS. Cab optional with air-conditioning.Reference
Variants
455Dloader tractorReference
455D TLBloader-backhoeReference
Engine
Ford 3.3L 3-cyl dieselReference
Engine (gross)49.2 kWReference
Engine (net)44.7 kWReference
FordReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement3.3 LReference
Bore/Stroke112 x 112 mmReference
Power (net)44.7 kWReference
Power (gross)49.2 kWReference
Rated RPM2200Reference
Starter volts12Reference
Transmission
4-speed power shuttleReference
Typepower shuttleReference
Gears4 forward and reverseReference
Fully synchronized transmission with power shuttle and torque converter.Reference
PTO & Hydraulics
Typeopen centerReference
Pump flow98.4 lpmReference
Backhoe & Loader
Dig depth436 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps55Reference
Battery volts12Reference
Battery AH80Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Ford Backhoe
Backhoe typeFord BackhoeReference
Digging depth436 cmReference
Loading height302 cmReference
Bucket force4681 kgReference
Dipperstick force3501 kgReference
Dimensions
2WD Max front axle5670 kgReference
4WD Max front axle6286 kgReference
4WD Front tread168 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
