Industrial Tractor · 1993Unverified
Ford 545D
Ford 545D — D Series · 66 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
66 hp
Weight
5015 to 10316 pounds
Hover a source tag to verify
Overview
ManufacturerFordReference
Industrial tractorReference
Two- or four-wheel driveReference
Power steeringReference
Wet multi-disc brakesReference
Two-post ROPS. Optional four-post ROPS. Optional two-door cab with heater.Reference
Engine
Ford 3.3L 3-cyl dieselReference
Engine (gross)49.2 kWReference
Engine (net)46.2 kWReference
FordReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement3.3 LReference
Bore/Stroke112 x 112 mmReference
Power (net)46.2 kWReference
Power (gross)49.2 kWReference
Compression16.3:1Reference
Rated RPM2200Reference
Torque244.1 NmReference
Torque RPM1400Reference
Starter volts12Reference
Oil capacity6.6 LReference
Coolant capacity10.4 LReference
Transmission
8-speed torque converterReference
4-speed torque converterReference
8-speedReference
Typetorque converterReference
Gears8 forward and reverseReference
Oil capacity16.1 LReference
Gears4 forward and reverseReference
Gears8 forward and 2 reverseReference
Oil capacity12.0 LReference
PTO & Hydraulics
Shuttle PTO (claimed)37.3 kWReference
Gear PTO (claimed)40.3 kWReference
Hydraulic system34.4 LReference
Typeopen centerReference
Capacity34.4 LReference
Pressure168.9 barReference
Valves1 or 2Reference
Pump flow98.4 lpmReference
Steering flow22.3 lpmReference
Steering cap.0.6 LReference
Steering press.110.3 barReference
Rear TypeII/IReference
Controlposition control and top-link draft sensingReference
Rear lift1397 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Capacities
Fuel60.6 LReference
Steering0.6 LReference
Dimensions
Wheelbase205 cmReference
Weight5015 to 10316 poundsReference
Ag front7.50-16 (2WD)Reference
Ag front12.0-16.5 (4WD)Reference
Ag rear16.9-24Reference
Ag rear16.9-28Reference
Length497 cmReference
Width198 cmReference
Height (ROPS)238 cmReference
Height (cab)236 cmReference
2WD Ground clearance35 cmReference
4WD Ground clearance27 cmReference
2WD Front tread147 cmReference
4WD Front tread168 cmReference
Rear tread154 cmReference
2WD ROPS2274 kgReference
2WD Cab2543 kgReference
4WD ROPS2555 kgReference
4WD Cab2823 kgReference
4WD Cab4081 kgReference
4WD Cab4361 kgReference
4WD Cab4399 kgReference
4WD Cab4679 kgReference
2WD Max front axle4536 kgReference
2WD Max front axle18144 kgReference
4WD Max front axle6282 kgReference
4WD Max front axle25147 kgReference
Max rear axle5216 kgReference
Max rear axle15649 kgReference
Ford 545D attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps55Reference
Battery CCA675Reference
Battery volts12Reference
Battery AH128Reference
Speeds
Speed with 16.9-28 rear tires.Reference
with 16.9-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
