Tractor · 1992Unverified

Ford 5530

Name: Ford 5530
Brand: Ford

Ford 5530 — High-Clearance tractor · 62 hp. Reference specifications; pending source verification.

The Ford 5530 is a compact tractor with a rated output of 62 hp, produced between 1992 and 1996. It features a 4-cylinder diesel liquid-cooled engine, and is equipped with four-wheel drive and a 12-speed gearbox. The listed weight of the tractor ranges from 5689 to 7290 pounds. The Ford 5530 is designed for use on plots of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

62 hp

Weight

5689 to 7290 pounds

Catalogue coverage

Variants represented

Richest spec table

60 rows

Recorded power

62 hp

Recorded weight

2580 kg

Transmissions

12-speed partially synchronized

Production years

1992-1996

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerFordReference

High-Clearance tractorReference

Built in ItalyReference

Original price was $25,300 in 1996Reference

Two- or four-wheel driveReference

Disc brakesReference

Four-post ROPS.Reference

Engine

Fiat 3.6L 4-cyl dieselReference

Fuel tank73.1 LReference

Fiat 8045.06Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.6 LReference

Bore/Stroke100 x 115 mmReference

Rated RPM2500Reference

StarterelectricReference

Starter volts12Reference

Oil capacity11.4 LReference

Transmission

12-speed partially synchronizedReference

20-speed synchromeshReference

Typepartially synchronizedReference

Gears12 forward and reverseReference

Four gears in three ranges with mechanical shuttle.Reference

TypesynchromeshReference

Gears20 forward and 12 reverseReference

Optional transmission adds two creeper ranges.Reference

PTO & Hydraulics

PTO (claimed)46.2 kWReference

Typeopen centerReference

Valves1 to 3Reference

Pump flow41.6 lpmReference

Rear TypeIIReference

Rear lift2355 kgReference

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Dimensions

2WD Wheelbase210 cmReference

4WD Wheelbase204 cmReference

Weight5689 to 7290 poundsReference

Front tire7.50x18Reference

2WD Rear tire9.50x42Reference

2WD Standard tires (ag)Front: 7.50x18. Rear: 9.50x42Reference

4WD Standard tires (ag)Front: 13.6x38. Rear: 13.6x38Reference

2WD Length377 cmReference

4WD Length410 cmReference

Height (ROPS)276 cmReference

2WD Weight2580 kgReference

4WD Weight3306 kgReference

2WD Clearance (front axle)80 cmReference

4WD Clearance (front axle)63 cmReference

2WD Clearance (drawbar)63 cmReference

4WD Clearance (drawbar)65 cmReference

2WD Front tread154 to 205 cmReference

4WD Front tread167 to 218 cmReference

2WD Rear tread142 to 193 cmReference

4WD Rear tread142 to 187 cmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps33Reference

Battery volts12Reference

Speeds

With 13.6x38 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
