Tractor · 1955Unverified

Ford 620

Name: Ford 620
Brand: Ford

Ford 620 — 600 Series · 30 hp. Reference specifications; pending source verification.

The Ford 620 is a tractor with a rated power output of 30 hp, positioning it at the lighter end of its class. It was manufactured from 1955 to 1957. The tractor features a 4-cylinder petrol liquid-cooled engine and a two-wheel drive system with a 4-speed gearbox. Its operating weight is listed at 1247 kg, with a capacity for operations of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

30 hp

Weight

1247 kg

Catalogue coverage

Variants represented

Richest spec table

67 rows

Recorded power

30 hp

Recorded weight

1247 kg

Transmissions

4-speed unsynchronized gear

Production years

1955-1957

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerFordReference

Utility tractorReference

Built in Highland Park, Michigan, USAReference

Two-wheel driveReference

SteeringmanualReference

Steeringpower assist optionalReference

Differential mechanical expanding shoe brakesReference

Open operator station.Reference

Variants

620no PTO, hydraulics, or 3-point hitchReference

630no PTOReference

640four-speedReference

650five-speedReference

660five-speed, live PTOReference

Engine

Ford 2.2L 4-cyl gasolineReference

Ford 2.2L 4-cyl LP gasReference

Fuel tank41.6 LReference

Belt (claimed)22.4 kWReference

Plows2 (14-inch)Reference

Ford EAE Red TigerReference

gasolineReference

4-cylinder 8-valveReference

liquid-cooled inlineReference

Displacement2.2 LReference

Bore/Stroke87 x 91 mmReference

EmissionsTier 0Reference

Air cleaneroil bathReference

Compression6.6:1Reference

Rated RPM2200Reference

Firing order1-2-4-3Reference

Starter volts6Reference

Coolant capacity14.2 LReference

Sparkplug14MMReference

Sparkplug gap0.635 mmReference

Sparkplug gap0.711 mmReference

Oil capacity4.7 LReference

Oil change100 hReference

LP gasReference

Sparkplug gap0.711 mmReference

Sparkplug gap0.787 mmReference

Transmission

4-speed unsynchronized gearReference

TransmissionFordReference

Typeunsynchronized gearReference

Gears4 forward and 1 reverseReference

Clutchdry discReference

Dimensions

Wheelbase191 cmReference

Weight1247 kgReference

Front tire5.50-16Reference

Rear tire10-28Reference

Ag front5.50-16Reference

Ag rear10-28Reference

Length308 cmReference

Width164 cmReference

Height149 cmReference

Ground clearance53 cmReference

Front tread132 to 193 cmReference

Rear tread132 to 193 cmReference

620 Serial Number Location

On the left-hand side of the transmission housing behind the starter.Reference

620 Serial Numbers

19541Reference

195510615Reference

195677271Reference

1957116368Reference

FAQ: How to read a serial number table.Reference

Electrical

GroundpositiveReference

Charging systemgeneratorReference

Charging amps20Reference

Battery volts6Reference

Speeds

With 10x28 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
