Backhoe Loader · 1993Unverified
Ford 655D
Ford 655D — D Series · 82 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
82 hp
Weight
1488 to 13179 pounds
Hover a source tag to verify
Overview
ManufacturerFordReference
Backhoe loader tractorReference
Two- or four-wheel driveReference
Differential lockrear standardReference
Power steeringReference
Wet disc brakesReference
Four-post ROPS/FOPS. Cab optional with air-conditioning.Reference
Engine
Ford 4.4L 4-cyl dieselReference
Engine (gross)61.1 kWReference
Engine (net)55.9 kWReference
FordReference
dieselReference
4-cylinderReference
liquid-cooledReference
A turbocharged 4.2L engine was available as a high-altitude option for the Ford 655D. Rated horsepower was the same as the naturally-aspirated engine.Reference
Displacement4.4 LReference
Bore/Stroke112 x 112 mmReference
Power (net)55.9 kWReference
Power (gross)61.1 kWReference
Compression16.3:1Reference
Rated RPM2200Reference
Torque287.5 NmReference
Torque RPM1200Reference
Starter volts12Reference
Oil capacity8.5 LReference
Coolant capacity16.0 LReference
Transmission
4-speed power shuttleReference
Typepower shuttleReference
Gears4 forward and reverseReference
Oil capacity16.1 LReference
Fully synchronized transmission with power shuttle and torque converter.Reference
Capacities
Fuel90.8 LReference
Steering2.4 LReference
PTO & Hydraulics
Hydraulic system79.5 LReference
Typeopen centerReference
Capacity79.5 LReference
Pressure182.7 barReference
Pump flow117.3 lpmReference
Steering flow19.3 lpmReference
Steering cap.2.4 LReference
Steering press.134.5 barReference
Dimensions
Wheelbase220 cmReference
Weight1488 to 13179 poundsReference
Front tire11L-16Reference
Rear tire16.9-28Reference
2WD Industrial front11L-16Reference
4WD Industrial front12.0-16.5Reference
Industrial rear16.9-28Reference
Length711 cmReference
Width220 cmReference
Height (ROPS)274 cmReference
Height (backhoe)393 cmReference
2WD Clearance (front axle)29 cmReference
4WD Clearance (front axle)27 cmReference
2WD Front tread177 cmReference
4WD Front tread173 cmReference
Rear tread172 cmReference
2WD ROPS5977 kgReference
4WD Cab674 kgReference
2WD Max front axle5670 kgReference
4WD Max front axle6286 kgReference
Max rear axle6123 kgReference
Backhoe & Loader
Dig depth472 cmReference
Dump angle114 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps55Reference
Battery CCA800Reference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Ford Backhoe
Backhoe typeFord BackhoeReference
Transport height393 cmReference
Digging depth472 cmReference
2-Foot flat digging depth469 cmReference
8-Foot flat digging depth434 cmReference
Reach from pivot591 cmReference
Loading height381 cmReference
Bucket Rotation154°Reference
Swing Arc180°Reference
Bucket force5066 kgReference
Dipperstick force3483 kgReference
Ford Xtra-vator Backhoe
Backhoe typeFord Xtra-vator BackhoeReference
Transport height388 cmReference
Digging depth (retracted stick)472 cmReference
Digging depth (extended stick)591 cmReference
2-Foot flat digging depth (retracted stick)469 cmReference
2-Foot flat digging depth (extended stick)589 cmReference
8-Foot flat digging depth (retracted stick)434 cmReference
8-Foot flat digging depth (extended stick)561 cmReference
Reach from pivot (retracted stick)591 cmReference
Reach from pivot (extended stick)701 cmReference
Loading height (retracted stick)388 cmReference
Loading height (extended stick)459 cmReference
Bucket Rotation166°Reference
Swing Arc180°Reference
Bucket force (retracted stick)5674 kgReference
Bucket force (extended stick)5674 kgReference
Dipperstick force (retracted stick)3542 kgReference
Dipperstick force (extended stick)2481 kgReference
Speeds
With 16.9-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
