Tractor · 1992Unverified
Ford 6630
Ford 6630 — 30 Superforça Series · 90 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
90 hp
Hover a source tag to verify
Overview
ManufacturerFord (a part of New Holland)Reference
Utility tractorReference
Built in Curitiba, BrazilReference
Two- or four-wheel driveReference
Two-post ROPS.Reference
Engine
Ford 5.0L 4-cyl dieselReference
Engine67.1 kWReference
FordReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement5.0 LReference
Bore/Stroke112 x 127 mmReference
Power67.1 kWReference
Starter volts12Reference
Transmission
8-speedReference
TransmissionDual PowerReference
Gears8 forward and 2 reverseReference
PTO & Hydraulics
Typeopen centerReference
Rear TypeIIReference
Rear PTOindependentReference
Rear PTO Type540Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
