Backhoe Loader · 1993Unverified
Ford 675D
Ford 675D — D Series · 93 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
93 hp
Hover a source tag to verify
Overview
ManufacturerFordReference
Backhoe loader tractorReference
Two- or four-wheel driveReference
Power steeringReference
Disc brakesReference
Four-post ROPS/FOPS. Cab optional with air-conditioning.Reference
Engine
Ford 4.4L 4-cyl dieselReference
Engine (gross)69.4 kWReference
Engine (net)64.1 kWReference
FordReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke112 x 112 mmReference
Power (net)64.1 kWReference
Power (gross)69.4 kWReference
Rated RPM2200Reference
Starter volts12Reference
Transmission
4-speed power shuttleReference
Typepower shuttleReference
Gears4 forward and reverseReference
Fully synchronized transmission with power shuttle and torque converter.Reference
PTO & Hydraulics
Typeopen centerReference
Backhoe & Loader
Dig depth472 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Ford Backhoe
Backhoe typeFord BackhoeReference
Digging depth472 cmReference
Loading height381 cmReference
Bucket force5066 kgReference
Dipperstick force3483 kgReference
Dimensions
2WD Max front axle5670 kgReference
4WD Max front axle6286 kgReference
4WD Front tread173 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
