Backhoe Loader · 1993Unverified

Ford 675D

Name: Ford 675D
Brand: Ford

Ford 675D — D Series · 93 hp. Reference specifications; pending source verification.

The Ford 675D is a backhoe loader with a rated power of 93 hp, a mid-range figure for its class. This model was built from 1993 to 1995. Power comes from a 4-cylinder turbocharged diesel liquid-cooled engine, paired with four-wheel drive with a 4-speed gearbox. It suits operations of 200–800 ac. See the table below for complete UK and US figures with sourcing.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

93 hp

Catalogue coverage

Variants represented

Richest spec table

38 rows

Recorded power

93 hp

Transmissions

4-speed power shuttle

Production years

1993-1995

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerFordReference

Backhoe loader tractorReference

Two- or four-wheel driveReference

Power steeringReference

Disc brakesReference

Four-post ROPS/FOPS. Cab optional with air-conditioning.Reference

Engine

Ford 4.4L 4-cyl dieselReference

Engine (gross)69.4 kWReference

Engine (net)64.1 kWReference

FordReference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement4.4 LReference

Bore/Stroke112 x 112 mmReference

Power (net)64.1 kWReference

Power (gross)69.4 kWReference

Rated RPM2200Reference

Starter volts12Reference

Transmission

4-speed power shuttleReference

Typepower shuttleReference

Gears4 forward and reverseReference

Fully synchronized transmission with power shuttle and torque converter.Reference

PTO & Hydraulics

Typeopen centerReference

Backhoe & Loader

Dig depth472 cmReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Battery volts12Reference

Attachment overview

Front-end loaderReference

BackhoeReference

Ford Backhoe

Backhoe typeFord BackhoeReference

Digging depth472 cmReference

Loading height381 cmReference

Bucket force5066 kgReference

Dipperstick force3483 kgReference

Dimensions

2WD Max front axle5670 kgReference

4WD Max front axle6286 kgReference

4WD Front tread173 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
