Lawn Tractor · 1968Unverified
Ford 70
Ford 70 — Lawn tractor · 7 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
7 hp
Weight
171 kg
Hover a source tag to verify
Overview
DistributorFordReference
ManufacturerJacobsenReference
Lawn tractorReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
70recoil startReference
75electric startReference
Engine
7HP Briggs & Stratton 275cc 1-cyl gasolineReference
Fuel tank3.8 LReference
Briggs & Stratton 170702Reference
gasolineReference
1-cylinderReference
air-cooled vertical-shaftReference
Displacement16.79 ciReference
Bore/Stroke76 x 60 mmReference
Power (gross)5.2 kWReference
Air cleanerdryReference
Rated RPM3600Reference
Starter typemanual recoilReference
Oil capacity0.7 LReference
Transmission
3-speed gearReference
Typebelt-driven gearReference
Gears3 forward and 1 reverseReference
Dimensions
Wheelbase106 cmReference
Weight171 kgReference
Front tire13x5.00-6Reference
Rear tire18x8.50-8Reference
Lawn/turf front13x5.00-6Reference
Lawn/turf rear18x8.50-8Reference
Length147 cmReference
Width81 cmReference
Height (steering wheel)93 cmReference
Ford 70 attachments
34" mid-mount mower deckReference
snowblowerReference
bladeReference
Attachment overview
34" mid-mount mower deckReference
SnowblowerReference
BladeReference
34" Mower deck
Typemid-mount FordReference
Type2-bladeReference
Cutting width86 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
