Tractor · 1971Unverified
Ford 7000
Ford 7000 — Utility tractor · 93 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
93 hp
Max power
49.7 kW
Weight
2857 kg
Hover a source tag to verify
Overview
ManufacturerFordReference
Utility tractorReference
Original price was $12,260 in 1975Reference
Two-wheel driveReference
SteeringmanualReference
Steeringhydrostatic powerReference
Open operator stationReference
Variants
7100all-purposeReference
7200row-cropReference
Engine
Ford 4.2L 4-cyl dieselReference
Fuel tank75.7 LReference
Engine (gross)69.4 kWReference
Engine (net)66.4 kWReference
Drawbar (tested)49.7 kWReference
FordReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.2 LReference
Bore/Stroke112 x 107 mmReference
Power (net)66.4 kWReference
Power (gross)69.4 kWReference
Air cleanerdryReference
Compression16.5:1Reference
Rated RPM2100Reference
Firing order1-3-4-2Reference
Starter volts12Reference
Coolant capacity13.7 LReference
Intake valve clearance0.381 mmReference
Exhaust valve clearance0.457 mmReference
Oil capacity8.5 LReference
Power at rated engine speed62.3 kWReference
Max power49.7 kWReference
Transmission
8-speed constant meshReference
16-speed two-speed power shiftReference
Typeconstant meshReference
Gears8 forward and 2 reverseReference
Oil capacity52.1 LReference
TransmissionDual PowerReference
Typetwo-speed power shiftReference
Gears16 forward and 4 reverseReference
Clutch330mm discReference
PTO & Hydraulics
PTO (claimed)61.9 kWReference
PTO (tested)62.3 kWReference
Type11.45Reference
Pressure172.4 barReference
Valves2Reference
Pump flow22.7 lpmReference
Steering flow10.4 lpmReference
Steering press.75.8 barReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear PTOindependentReference
Rear PTO Type540Reference
Rear PTO Type540/1000Reference
Engine RPM540@1900Reference
Engine RPM1000@2060Reference
Power at rated PTO speed58.8 kWReference
Dimensions
Wheelbase222 cmReference
Weight2857 kgReference
Front tire6.00-16Reference
Rear tire13.6-38Reference
Ag front6.00-16Reference
Ag rear13.6-38Reference
Ag rear12.4-36Reference
Ag front7.50-15Reference
Ag front7.50-16Reference
Ag front7.50-18Reference
Ag front7.50-20Reference
Ag rear15.5-38Reference
Ag rear16.9-30Reference
Ag rear16.9-34Reference
Ag rear16.9-38Reference
Ag rear18.4-30Reference
Ag rear18.4-34Reference
Length359 cmReference
Width173 cmReference
Height (hood)154 cmReference
Height (exhaust)243 cmReference
Operating weight2857 kgReference
Ballasted weight4896 kgReference
Ground clearance45 cmReference
Ground clearance41 cmReference
Ford 7000 attachments
front-end loaderReference
7000 Serial Numbers
1971C292100Reference
1972C327200Reference
1973C367300Reference
1974C405200Reference
1975C450700Reference
FAQ: How to read a serial number table.Reference
Links
Dave's 7000: Information and specifications on the Ford 7000Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps55Reference
Battery volts12Reference
Battery AH128Reference
Test results
Diesel 8-speed 2WDApril 10 - 20, 1972Link: Nebraska Tractor Test 1093 fileReference
PTO performanceReference
Fuel use19.3 l/hourReference
Fuel use17.8 l/hourReference
Drawbar performanceReference
Fuel use18.9 l/hourReference
Gear 4 used for power test.Reference
Max pull3691 kgReference
Gear 2 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
