Tractor · 1973Unverified
Ford 7200
Ford 7200 — Row-Crop tractor · 89 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
89 hp
Weight
2835 kg
Hover a source tag to verify
Overview
ManufacturerFordReference
Row-Crop tractorReference
Two-wheel driveReference
Power steeringReference
Wet disc brakesReference
Open operator station.Reference
Variants
7000all-purposeReference
7200row-cropReference
Engine
Ford 4.2L 4-cyl dieselReference
Fuel tank75.7 LReference
Engine (net)66.4 kWReference
FordReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.2 LReference
Bore/Stroke112 x 107 mmReference
Power (net)66.4 kWReference
Compression16.5:1Reference
Rated RPM2100Reference
Starter volts12Reference
Transmission
16-speedReference
TransmissiongearReference
Gears16 forward and 8 reverseReference
PTO & Hydraulics
PTO (claimed)61.9 kWReference
Rear TypeIIReference
Rear PTOindependentReference
Rear PTO Type540Reference
Rear PTO Type540/1000Reference
Dimensions
Weight2835 kgReference
Front tire7.50-16Reference
Rear tire13.6-38Reference
Ag front7.50-16Reference
Ag rear13.6-38Reference
Ag front7.50-18Reference
Ag rear15.5-38Reference
Ag rear36.9-34Reference
Ag rear18.4-30Reference
Height (hood)160 cmReference
Shipping weight2835 kgReference
Electrical
Ground140Reference
Charging systemalternatorReference
Charging amps55Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
