Tractor · 1992Unverified
Ford 7530
Ford 7530 — High-Clearance tractor · 91 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
91 hp
Weight
3662 kg
Hover a source tag to verify
Overview
ManufacturerFordReference
High-Clearance tractorReference
Original price was $40,000 in 1996Reference
Drive4x4 4WDReference
Disc brakesReference
Four-post fixed ROPS.Reference
Engine
Fiat 5.4L 6-cyl dieselReference
Fuel tank128.7 LReference
Fiat 8065.06Reference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.4 LReference
Bore/Stroke100 x 115 mmReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Oil capacity13.6 LReference
Transmission
20-speed synchromeshReference
TypesynchromeshReference
Gears20 forward and 4 reverseReference
Five gears in four ranges.Reference
PTO & Hydraulics
PTO (claimed)67.9 kWReference
Typeopen centerReference
Valves2 or 3Reference
Pump flow43.9 lpmReference
Rear TypeIIReference
Rear lift2654 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase254 cmReference
Weight3662 kgReference
Front tire13.6x38Reference
Rear tire13.6x46Reference
Ag front13.6x38Reference
Ag rear13.6x46Reference
Length426 cmReference
Height (ROPS)274 cmReference
Clearance (front axle)63 cmReference
Clearance (drawbar)50 cmReference
Front tread165 to 215 cmReference
Rear tread160 to 213 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps65Reference
Battery volts12Reference
Speeds
With 13.6x46 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
