Tractor · Unverified
Ford 7610 Orchard
Ford 7610 Orchard — 10 SeriesOrchard/Vineyard tractor · 86 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
86 hp
Weight
2792 kg
Hover a source tag to verify
Overview
ManufacturerFordReference
Orchard/Vineyard tractorReference
Two- or four-wheel driveReference
Open operator station.Reference
Variants
7610utilityReference
7610Olow-profileReference
Engine
Ford 4.4L 4-cyl dieselReference
FordReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke112 x 112 mmReference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed gearReference
8-speed synchromeshReference
16-speed two-speed power shiftReference
TypegearReference
Gears8 forward and 2 reverseReference
TypesynchromeshReference
Gears8 forward and 4 reverseReference
TransmissionDual PowerReference
Typetwo-speed power shiftReference
Gears16 forward and 4 reverseReference
PTO & Hydraulics
PTO (claimed)64.1 kWReference
Typeopen centerReference
Pressure144.8 barReference
Pump flow68.9 lpmReference
Rear TypeIIReference
Rear PTOindependentReference
Rear PTO Type540Reference
Dimensions
Wheelbase221 cmReference
Weight2792 kgReference
Front tire7.50x16Reference
Rear tire16.9x24Reference
Standard tires (ag)Front: 7.50x16. Rear: 16.9x24Reference
Width179 cmReference
Height (steering wheel)167 cmReference
Shipping weight2792 kgReference
Clearance (front axle)38 cmReference
Front tread132 to 203 cmReference
Rear tread137 to 198 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps52Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
