Tractor · 1992Unverified

Ford 7630

Name: Ford 7630
Brand: Ford

Ford 7630 — 30 SuperforÃ§a Series · 103 hp. Reference specifications; pending source verification.

The Ford 7630 is a tractor with an engine rating of 103 hp, placing it towards the middle of its class in terms of power output. Manufactured from 1992 to 1997, this model features a 4-cylinder turbocharged diesel liquid-cooled engine, connected to a four-wheel drive system and an 8-speed gearbox. Its listed weight is 3628 kg, making it suitable for agricultural jobs involving areas of approximately 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

103 hp

Weight

3628 kg

Catalogue coverage

Variants represented

Richest spec table

30 rows

Recorded power

103 hp

Recorded weight

3628 kg

Transmissions

8-speed

Production years

1992-1997

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerFord (a part of New Holland)Reference

Utility tractorReference

Built in Curitiba, BrazilReference

Four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Two-post ROPS.Reference

Engine

Ford 5.0L 4-cyl dieselReference

Engine76.8 kWReference

FordReference

turbocharged dieselReference

4-cylinderReference

liquid-cooledReference

Displacement5.0 LReference

Bore/Stroke112 x 127 mmReference

Power76.8 kWReference

Starter volts12Reference

Transmission

8-speedReference

TransmissionDual PowerReference

Gears8 forward and 2 reverseReference

PTO & Hydraulics

Typeopen centerReference

Pump flow34.8 lpmReference

Rear TypeIIReference

Rear PTOindependentReference

Rear PTO Type540Reference

Dimensions

Wheelbase227 cmReference

Weight3628 kgReference

Length411 cmReference

Height286 cmReference

Electrical

Charging systemalternatorReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
