Tractor · 1985Unverified
Ford 7910
Ford 7910 — Row-Crop tractor · 98 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
98 hp
Weight
5225 kg
Hover a source tag to verify
Overview
ManufacturerFordReference
Row-Crop tractorReference
Two- or four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Engine
Ford 6.6L 6-cyl dieselReference
Fuel tank177.9 LReference
Engine73.1 kWReference
FordReference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement6.6 LReference
Bore/Stroke112 x 112 mmReference
Power73.1 kWReference
Rated RPM2100Reference
Torque390.0 NmReference
Torque RPM1000Reference
Transmission
16-speedReference
Gears16 forward and 8 reverseReference
PTO & Hydraulics
Pump flow68.9 lpmReference
Rear lift4100 kgReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase289 cmReference
Weight5225 kgReference
Front tire11.00-16Reference
Rear tire16.9-38Reference
Ag front11.00-16 (2WD)Reference
Ag front13.6-28 (4WD)Reference
Ag rear16.9-38Reference
Length436 cmReference
Height279 cmReference
Weight5225 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
