Industrial Tractor · 1968Unverified
Ford 8400
Ford 8400 — Industrial tractor · 125 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
125 hp
Weight
5005 kg
Hover a source tag to verify
Overview
ManufacturerFordReference
Industrial tractorReference
Two-wheel driveReference
Final drivesplanetaryReference
Differential lockhydraulic rearReference
Power steeringReference
Open operator station. Cab optional.Reference
Variants
8000farm tractorReference
Engine
Ford 6.6L 6-cyl dieselReference
Fuel tank162.8 LReference
Engine (gross)93.1 kWReference
Engine (net)80.8 kWReference
FordReference
dieselReference
6-cylinderReference
liquid-cooled inlineReference
Displacement6.6 LReference
Bore/Stroke112 x 112 mmReference
Power (net)80.8 kWReference
Power (gross)93.1 kWReference
Fuel systemdirect injectionReference
Air cleanerdryReference
Compression16.5:1Reference
Rated RPM2300Reference
Torque415.6 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Oil capacity11.4 LReference
Coolant capacity17.0 LReference
Transmission
8-speed gearReference
16-speed two-speed power shiftReference
TransmissionDual RangeReference
TypegearReference
Gears8 forward and 2 reverseReference
TransmissionDual PowerReference
Typetwo-speed power shiftReference
Gears16 forward and 4 reverseReference
PTO & Hydraulics
PTO (claimed)78.8 kWReference
Typeopen centerReference
Pressure172.4 barReference
Pump flow45.4 lpmReference
Pump flow60.6 lpmReference
Steering flow15.9 lpmReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase232 cmReference
Weight5005 kgReference
Front tire7.50-18Reference
Rear tire23.1-30Reference
Industrial front7.50-18Reference
Industrial rear23.1-30Reference
Length391 cmReference
Width231 cmReference
Height (steering wheel)234 cmReference
Height (hood)188 cmReference
Clearance (front axle)64 cmReference
Clearance (rear axle)46 cmReference
Front tread142 to 213 cmReference
Rear tread172 to 203 cmReference
Electrical
Charging systemalternatorReference
Charging amps55Reference
Battery volts12Reference
Battery AH128Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
